Product Overview
The PARKER F11-010-MB-CV-K-209-0000-0X (OEM Reference: 3798391) is a high-performance axial piston motor from Parker Hannifin’s renowned F11 series, engineered for demanding industrial and mobile hydraulic applications. Utilizing a bent-axis axial piston design, this fixed-displacement motor converts hydraulic fluid power into reliable rotary mechanical output with exceptional volumetric and mechanical efficiency. The F11 series is globally recognized for its compact, lightweight construction, high power density, and superior performance in both open and closed-loop hydraulic circuits. With a nominal displacement of 10 cm³/rev, this motor is ideally suited for continuous-duty operation in applications requiring precise torque delivery, high starting efficiency, and long service life.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Axial Piston Motor (Bent-Axis Design) |
| Model Designation | F11-010-MB-CV-K-209-0000-0X / 3798391 |
| Nominal Displacement | 10 cm³/rev (0.61 in³/rev) |
| Operating Pressure | Continuous: up to 350 bar (5,076 psi) / Peak: up to 420 bar (6,091 psi) |
| Maximum Speed | Up to 6,000 RPM (dependent on circuit conditions) |
| Mounting & Connection | Standard SAE / ISO Flange, Splined Shaft Interface |
| Control Type | Fixed Displacement (MB Configuration) |
| Direction of Rotation | Bi-directional |
Engineering Features & Advantages
- Precision Performance: The bent-axis axial piston design delivers high starting torque and excellent low-speed stability, ensuring smooth operation even under heavy load conditions with minimal pressure ripple.
- High Power Density: Compact and lightweight construction allows for space-saving integration without compromising torque output or pressure capability.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, featuring hardened piston/cylinder interfaces and high-grade bearing systems for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, ensuring drop-in replacement for Parker F11 series motors with matching model codes.
- Versatile Circuit Compatibility: Suitable for both open and closed-loop hydraulic systems, with bi-directional operation and excellent volumetric efficiency across the full speed range.
Typical Industrial Applications
This Parker F11-010 axial piston motor is commonly deployed in plastic injection molding machines, metallurgical presses and rolling mills, construction and marine hydraulic drive systems, CNC machine tool rotary axes, and mobile equipment winch and wheel drive circuits. Its robust bent-axis design and high-pressure capability make it a preferred choice for applications demanding precise torque control, high duty cycles, and dependable performance in harsh operating environments
PRODUCT IMAGES
PARKER F11-010-MB-CV-K-209-0000-0X / 3798391 Axial Piston Motor
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine PARKER F11-010-MB-CV-K-209-0000-0X / 3798391 Hydraulic Axial Piston Pump. This UK-made fixed displacement pump features a compact design, delivering reliable, high-pressure fluid power for demanding industrial systems.
