Product Overview
The Parker PS1-E116 (part number 12000503) is a direct-acting solenoid operated directional control valve from Parker’s PS1 series, engineered for precise control of hydraulic fluid flow direction in industrial power units and manifold-mounted circuits. Utilizing a robust wet-armature solenoid design and a hardened, precision-ground spool, this valve shifts flow paths on command to extend, retract, or hold actuators in position. Its compact 2-position, 4-way configuration makes it an ideal building block for sequencing, interlocking, and load-holding functions in demanding hydraulic systems where fast, repeatable response and leak-tight sealing are essential.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Directional Control Valve (Solenoid Operated) |
| Model Designation | PS1-E116 / 12000503 |
| Manufacturer | Parker Hannifin |
| Valve Configuration | 4-Way, 2-Position (4/2) Spool Type |
| Actuation Method | Direct-Acting Wet-Pin Solenoid, Spring Return |
| Operating Pressure | Standard Industrial Grade (Up to 350 bar rated) |
| Nominal Flow Capacity | Up to 40 L/min (dependent on spool/spool options) |
| Mounting & Connection | Subplate / Manifold Mounting, ISO 4401 / CETOP 3 Interface |
| Seal Material | NBR (Buna-N) Standard, FKM Optional |
| Electrical Supply | Standard Industrial Solenoid Voltage (e.g., 24 VDC / 230 VAC) |
Engineering Features & Advantages
- Precision Spool Metering: Hardened, precision-ground spool and sleeve assembly delivers accurate flow metering, minimal internal leakage, and consistent shift response across the full pressure range.
- Wet-Armature Solenoid Design: Oil-immersed solenoid armature provides smooth, quiet actuation, excellent heat dissipation, and long service life under continuous duty cycles.
- Fast, Repeatable Response: Direct-acting solenoid ensures rapid shifting with short response times, critical for high-cycle sequencing and interlock circuits.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust coil encapsulation and corrosion-resistant construction.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Parker OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
Its compact 2-position, 4-way configuration makes it an ideal building block for sequencing, interlocking, and load-holding functions in demanding hydraulic systems where fast, repeatable response and leak-tight sealing are essential.
PRODUCT IMAGES
Parker PS1-E116 / 12000503 Solenoid Directional Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Parker PS1-E116 / 12000503 Solenoid Directional Valve. This Germany-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
