Product Overview

The Parker PV180R1K1T1NMMC / PV180R1K1N01NSD4 is a heavy-duty axial piston pump from the Parker PV series, engineered for high-pressure open-circuit hydraulic systems. Utilizing a proven swashplate design with a rotating cylinder barrel and precision-ground axial pistons, this pump delivers reliable variable displacement performance with excellent volumetric efficiency. The PV180 frame size is rated for continuous operation up to 350 bar, making it a preferred choice for demanding industrial applications requiring precise flow control and long service life. The dual model designation indicates configuration variants covering different control types and mounting interfaces within the same PV180 displacement family.

Technical Specifications

Parameter	Specification / Feature
Component Type	Hydraulic Piston Pump (Axial Piston, Variable Displacement)
Model Designation	PV180R1K1T1NMMC / PV180R1K1N01NSD4
Manufacturer	Parker Hannifin
Displacement (Nominal)	180 cm³/rev (PV180 frame size)
Operating Pressure	Up to 350 bar continuous / 420 bar peak
Working Principle	Swashplate axial piston, variable displacement, open circuit
Mounting & Connection	SAE standard flange, splined drive shaft, ISO 6162 port connections
Control Type	Pressure / Load-Sensing / Torque Control (per model suffix)
Speed Range	Up to 2,200 rpm (dependent on inlet conditions)

Engineering Features & Advantages

Precision Swashplate Performance: The axial piston design with hardened swashplate and precision-ground pistons ensures smooth, stepless displacement control with minimal pressure ripple and high volumetric efficiency across the full operating range.
High-Pressure Capability: Rated for continuous operation up to 350 bar, the PV180 delivers exceptional power density suitable for the most demanding hydraulic circuits in heavy industry.
Robust Cylinder Barrel & Valve Plate: The rotating group features a durable cylinder barrel and bronze-faced valve plate that minimize wear and extend service intervals even under high thermal loads.
Flexible Control Options: Available with multiple control configurations (pressure compensator, load sensing, torque limiting) to match specific system requirements and optimize energy efficiency.
Industrial Reliability: Built for continuous operation under severe industrial conditions with heavy-duty bearings and a rigid housing that resists vibration and shock loading.
Direct Fit Replacement: Exact dimensional and functional compatibility with original PARKER OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.

Typical Industrial Applications

The PV180 frame size is rated for continuous operation up to 350 bar, making it a preferred choice for demanding industrial applications requiring precise flow control and long service life.

PRODUCT IMAGES

PARKER PV180R1K1T1NMMC / PV180R1K1N01NSD4 Axial Piston Pump

⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:

Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
Peace of Mind: Covered by our 12-Month Replacement Warranty.

Shop the genuine PARKER PV180R1K1T1NMMC / PV180R1K1N01NSD4 Piston Pump. This US-made hydraulic component features a variable displacement design, delivering reliable fluid power for heavy-duty industrial systems.
