Product Overview
The Parker R10M35S4SN38 KU is a pilot-operated proportional pressure relief valve from Parker’s R10 series, engineered for precise, infinitely variable pressure control in demanding industrial hydraulic systems. Unlike fixed-setting relief valves, this unit modulates its pressure setting in direct proportion to an electrical command signal supplied to the integrated proportional solenoid, allowing the system pressure to be continuously ramped, held, or profiled under electronic control. The valve functions as a normally closed pressure-limiting element: when system pressure reaches the commanded setpoint, the pilot stage opens and hydraulically unbalances the main spool, diverting excess flow to tank and thereby capping circuit pressure. The “KU” designation identifies the proportional solenoid and control configuration, while the R10M frame size and 35 bar pressure range make it well suited to low-pressure pilot circuits, clamping and clamping-release loops, and pressure-regulated sub-circuits where smooth, repeatable pressure transitions are critical. As a proportional valve, it is intended for use with a Parker-compatible proportional amplifier card or a modern electronic control module capable of delivering a stable current output with dither.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Pressure Relief Valve (pilot-operated, solenoid-actuated) |
| Model Designation | R10M35S4SN38 KU |
| Series / Frame Size | Parker R10M proportional relief valve series |
| Pressure Range | Proportional adjustment up to approximately 35 bar (low-pressure pilot duty) |
| Actuation | Proportional solenoid with current-controlled pressure setting |
| Control Signal | Analog current command via proportional amplifier card (PWM/dither capable) |
| Operating Pressure | Standard Industrial Grade (up to rated bar) |
| Mounting & Connection | Standard ISO / Manufacturer Interface (subplate or manifold mounting) |
| Hydraulic Fluid | Mineral-based hydraulic oil, ISO VG 32–68 typical |
| Seal Material | NBR (standard); FKM available for elevated temperature service |
Engineering Features & Advantages
- Precision Performance: Infinitely variable pressure setting proportional to solenoid current, enabling smooth pressure ramps, soft-start sequences, and closed-loop pressure profiling without mechanical adjustment.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Parker standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
The Parker R10M35S4SN38 KU is a pilot-operated proportional pressure relief valve from Parker’s R10 series, engineered for precise, infinitely variable pressure control in demanding industrial hydraulic systems.
PRODUCT IMAGES
Parker R10M35S4SN38 KU Proportional Pressure Relief Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Parker R10M35S4SN38 KU Solenoid Directional Control Valve. This USA-made 24V DC hydraulic component features a 4-way 3-position design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
