Product Overview
The Parker RE06M25W2V1KW20 is a high-performance proportional pressure relief valve from Parker’s renowned RE series, engineered for precise electro-hydraulic pressure control in demanding industrial hydraulic systems. This pilot-operated proportional valve utilizes a proportional solenoid to infinitely vary the pressure setting in direct proportion to the electrical input signal, enabling smooth, dynamic pressure regulation rather than fixed-step adjustment. As a critical pressure control component, it safeguards hydraulic circuits against overpressure while providing programmable pressure profiles for complex machine sequences. The RE06M25W2V1KW20 is designed for direct integration into manifold blocks or subplate mounting configurations, delivering exceptional repeatability, low hysteresis, and fast response characteristics essential for closed-loop pressure control applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Pressure Relief Valve (Pilot-Operated) |
| Model Designation | RE06M25W2V1KW20 |
| Series | Parker RE Series Proportional Valves |
| Nominal Size | NG06 (CETOP 3 / ISO 4401-03) |
| Actuation Type | Proportional Solenoid with Integrated Position Feedback |
| Operating Pressure | Up to 315 bar (standard industrial grade) |
| Pressure Adjustment Range | 25 bar (M25 pressure stage designation) |
| Electrical Interface | Proportional solenoid, 24V DC nominal, with integrated amplifier option (KW20 designation) |
| Mounting & Connection | Subplate mounting per ISO 4401-03 / CETOP 3 interface |
| Seal Material | NBR (Buna-N) standard; FKM available on request |
| Fluid Compatibility | Mineral oil based hydraulic fluids per DIN 51524 |
| Operating Temperature | -20°C to +80°C (fluid temperature range) |
Engineering Features & Advantages
- Precision Performance: The proportional pressure relief valve (pilot-operated) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Parker standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
The RE06M25W2V1KW20 is designed for direct integration into manifold blocks or subplate mounting configurations, delivering exceptional repeatability, low hysteresis, and fast response characteristics essential for closed-loop pressure control applications.
PRODUCT IMAGES
Parker RE06M25W2V1KW20 Proportional Pressure Relief Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Parker RE06M25W2V1KW20 Proportional Directional Control Valve. This Germany-made 24V DC hydraulic component features a 4-way proportional design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
