Product Overview
The Parker T7BBS B10 B02 1R01 A1M0 is a high-performance double vane pump from the Parker T7 series, engineered for demanding industrial hydraulic systems requiring two independent flow outputs from a single drive shaft. This tandem configuration combines two T7 series vane pump cartridges within a common housing, delivering reliable, low-pulsation flow for dual-circuit applications. The T7BBS design utilizes Parker’s advanced intra-vane technology, where the vane geometry provides balanced hydraulic loading against the cam ring, minimizing wear and extending service life. With a nominal displacement combination of 10 and 2 cm³/rev, this pump is ideally suited for systems requiring a high-flow primary circuit and a lower-flow secondary circuit, such as clamping, pilot, or lubrication functions. The robust cast-iron construction and precision-machined components ensure stable volumetric efficiency and quiet operation across the full operating pressure range.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Vane Pump (Double / Tandem Configuration) |
| Model Designation | T7BBS B10 B02 1R01 A1M0 |
| Series | Parker T7 Series (Intra-Vane Design) |
| Displacement (Primary / Secondary) | 10 cm³/rev (B10) / 2 cm³/rev (B02) |
| Operating Pressure | Up to 210 bar continuous (primary cartridge); up to 140 bar (secondary cartridge) |
| Speed Range | 600 – 2800 rpm (dependent on fluid viscosity and pressure) |
| Mounting & Connection | SAE 2-bolt flange mounting; splined or keyed drive shaft; SAE flange ports |
| Rotation | Clockwise (1R01 designation) |
| Seal Material | NBR (Buna-N) standard; Viton available on request |
| Fluid Compatibility | Mineral-based hydraulic oil, ISO VG 32–68; fire-resistant fluids with appropriate seals |
| Weight (approx.) | 18 – 22 kg (depending on port configuration) |
Engineering Features & Advantages
- Precision Performance: The hydraulic vane pump (double / tandem configuration) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Parker standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
With a nominal displacement combination of 10 and 2 cm³/rev, this pump is ideally suited for systems requiring a high-flow primary circuit and a lower-flow secondary circuit, such as clamping, pilot, or lubrication functions.
PRODUCT IMAGES
Parker T7BBS B10 B02 1R01 A1M0 Double Vane Pump
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Parker T7BBS B10 B02 1R01 A1M0 Hydraulic Directional Control Valve. This Germany-made 24V DC hydraulic component features a 4-way 3-position design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
