The REXROTH 0510665394 / 1517222382 is a heavy-duty industrial high pressure gear pump engineered for continuous operation in demanding hydraulic circuits. Its external gear design provides positive displacement with minimal pulsation, ensuring stable flow and pressure across a wide speed range.
REXROTH 0510665394 / 1517222382 Technical Specifications
| Parameter | Specification |
|---|---|
| Displacement | 22.5 cm³/rev |
| Max. Continuous Pressure | 250 bar |
| Max. Peak Pressure | 280 bar |
| Max. Speed | 3000 rpm |
| Min. Speed | 500 rpm |
| Rotation | Clockwise |
| Mounting Flange | SAE 2-bolt |
| Shaft Type | Straight keyed |
| Port Connections | SAE split flange |
| Operating Temperature | -20 °C to +80 °C |
| Hydraulic Fluid | Mineral oil, HLP/HM per DIN 51524 |
| Weight | 9.8 kg |
Key Engineering Features
- External gear pair with pressure-balanced bearing blocks for high volumetric efficiency
- Case-hardened and ground gear teeth for low noise and long service life
- Aluminum alloy housing with cast-iron end covers for structural rigidity
- Integrated pressure relief valve option available for circuit protection
- Multi-fluid compatibility including mineral oil and selected synthetic fluids
- Compact footprint with SAE mounting for direct integration into existing systems
Industrial Applications
- Mobile hydraulic systems: excavators, loaders, cranes
- Industrial power units and hydraulic power packs
- Machine tool clamping and actuation circuits
- Material handling and lifting equipment
- Agricultural machinery hydraulic drives
- Marine and offshore hydraulic control systems
For technical inquiries, dimensional drawings, or replacement support for REXROTH 0510665394 / 1517222382, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
REXROTH 0510665394 / 1517222382 High Pressure Gear Pump
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the REXROTH 0510665394 / 1517222382 High Pressure Gear Pump. This precision-engineered industrial component delivers reliable fluid control for heavy-duty systems.
