Product Overview
The Rexroth 3DREME 10P-73/315YG24K31A1V (material number R901240745) is a direct-operated, three-way proportional pressure reducing valve from the Bosch Rexroth DREME series. It is designed to convert an electrical input signal into a continuously variable, infinitely adjustable reduced outlet pressure, providing precise electro-hydraulic control of secondary pressure circuits in industrial hydraulic systems. The valve operates on a proportional solenoid principle: the solenoid force acts directly against a pressure-setting spring and the feedback pressure at the control spool, establishing a force balance that determines the regulated output pressure. This three-way configuration (P, A, T ports) permits both pressure reduction and pressure relief of the consumer line, making it suitable for applications requiring accurate, dynamic pressure regulation independent of flow demand. The 3DREME 10P-73/315YG24K31A1V is a direct replacement component for Rexroth proportional pressure control circuits and is widely used in machine tools, injection molding equipment, and general industrial hydraulic power units.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Pressure Reducing Valve (Three-Way, Direct-Operated) |
| Model Designation | 3DREME 10P-73/315YG24K31A1V / R901240745 |
| Manufacturer | Bosch Rexroth |
| Size / Nominal Diameter | NG10 (Size 10) per ISO 4401 / DIN 24340 |
| Maximum Operating Pressure | 315 bar (system pressure at port P) |
| Pressure Regulation Range | Up to 315 bar reduced outlet pressure (proportional to command signal) |
| Actuation | Proportional solenoid, single solenoid with spring return |
| Solenoid Voltage | 24 V DC (G24 designation) |
| Electrical Connection | K31A1V — component plug / connector per Rexroth standard (K31) |
| Mounting & Connection | Subplate mounting, ISO 4401-05 / NG10 interface, 4-way port pattern (P, A, T) |
| Seal Material | NBR (standard mineral oil compatible) |
Engineering Features & Advantages
- Precision Performance: The integrated proportional solenoid, single solenoid with spring return ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Precision-manufactured to original Rexroth specifications for direct replacement, minimising downtime and eliminating fitment issues.
- Rated Capability: Rated for pressure ratings of 315 bar (system pressure at port P), supporting stable operation across the full working range.
Typical Industrial Applications
The 3DREME 10P-73/315YG24K31A1V is a direct replacement component for Rexroth proportional pressure control circuits and is widely used in machine tools, injection molding equipment, and general industrial hydraulic power units.
PRODUCT IMAGES
Rexroth 3DREME 10P-73/315YG24K31A1V / R901240745 Proportional Pressure Reducing Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Rexroth 3DREME 10P-73/315YG24K31A1V / R901240745 Proportional Directional Valve. This Germany-made 24 VDC hydraulic component features a direct-operated proportional design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
