The REXROTH 3DREME10P-73/200YG24K31F1M is a heavy-duty industrial proportional directional valve engineered for precise, continuous control of flow direction and magnitude in hydraulic systems. As part of the Rexroth 3DREME series, it features a direct-operated, wet-pin solenoid design with a spring-centered, three-position spool. The valve provides proportional flow characteristics in both directions, enabling smooth acceleration and deceleration of actuators. The integrated control electronics (type 31F1M) offer factory-set or field-adjustable parameters for optimal system response. With a nominal size of 10 (NG10) and a maximum operating pressure of 200 bar, this valve is suitable for demanding industrial applications requiring high dynamics and repeatability.
REXROTH 3DREME10P-73/200YG24K31F1M Technical Specifications
| Parameter | Value |
|---|---|
| Valve Type | Proportional Directional Valve, 3-way, 3-position |
| Nominal Size | NG10 (CETOP 5, ISO 4401-05) |
| Maximum Operating Pressure | 200 bar (port P, A, B) |
| Nominal Flow | 75 L/min at Δp = 10 bar per land |
| Spool Type | P-type, progressive flow characteristics |
| Actuation | Proportional solenoid, wet-pin, 24 V DC |
| Electrical Connection | Connector according to EN 175301-803, 3-pole + PE |
| Integrated Electronics | Type 31F1M, with position feedback and current control |
| Mounting Pattern | Subplate mounting, ISO 4401-05-04-0-05 |
| Seal Material | NBR (nitrile rubber) |
| Fluid Temperature Range | -20 °C to +80 °C |
| Viscosity Range | 10 to 500 mm²/s |
| Filtration | ISO 4406 (c) 18/16/13 or better |
| Weight | Approx. 6.5 kg |
Key Engineering Features
- Direct-operated proportional solenoid with wet-pin armature for high magnetic efficiency and low hysteresis.
- Spring-centered three-position spool ensures fail-safe neutral position in case of power loss.
- Integrated control electronics (31F1M) provide closed-loop position control, enabling precise repeatability and fast response.
- Progressive flow characteristics (P-type spool) allow fine control at low flow rates and high flow capacity at full stroke.
- Robust housing and precision-machined spool and sleeve for long service life and minimal internal leakage.
- Compatible with mineral oil-based hydraulic fluids and HFC/HFD fluids upon request.
- Standard CETOP/ISO mounting interface for easy integration into existing manifolds.
Industrial Applications
- Injection molding machines – precise control of injection, clamping, and ejector movements.
- Hydraulic presses – proportional control of ram speed and pressure.
- Machine tools – feed and positioning axes requiring high dynamic response.
- Steel and metallurgy – continuous casting and rolling mill adjustments.
- Test rigs and simulators – accurate force and motion control.
- Material handling – smooth acceleration and deceleration of heavy loads.
For technical inquiries, dimensional drawings, or replacement support for REXROTH 3DREME10P-73/200YG24K31F1M, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
REXROTH 3DREME10P-73/200YG24K31F1M Proportional Directional Valve
