Product Overview
The Rexroth 4WE 10 E50/HG24N9K4/M (Material Number R901390857) is a direct-operated, solenoid-actuated directional spool valve from the proven Rexroth 4WE 10 series. Designed for controlling the start, stop, and direction of fluid flow in industrial hydraulic systems, this valve features a robust three-position, four-way (4/3) spool configuration with a closed-center (E) spool type. The valve is actuated by a high-performance 24 V DC wet-pin solenoid (HG24) with a nominal voltage of 24 V DC, and includes a concealed manual override (N9) for emergency operation. The K4 designation indicates an ISO 4401-05 (NG10 / CETOP 5) mounting interface with a standard subplate pattern. With a maximum operating pressure of 350 bar and a nominal flow capacity of up to 120 L/min, this valve is engineered for precise directional control in demanding industrial applications requiring reliable, repeatable performance.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Spool Valve (4/3 Way) |
| Model Designation | 4WE 10 E50/HG24N9K4/M / R901390857 |
| Spool Type | Type E — Closed Center (All Ports Blocked in Neutral) |
| Actuation | High-Performance Wet-Pin Solenoid, 24 V DC (HG24) |
| Manual Override | Concealed Manual Override (N9) |
| Mounting Interface | ISO 4401-05 / CETOP 5 / NG10 (K4 Subplate Pattern) |
| Maximum Operating Pressure | Up to 350 bar (Ports P, A, B); 210 bar (Port T) |
| Nominal Flow Rate | Up to 120 L/min (dependent on spool and pressure drop) |
| Operating Pressure Range | Standard Industrial Grade (Up to rated bar) |
| Mounting & Connection | Standard ISO / Manufacturer Interface |
| Hydraulic Fluid | Mineral Oil (HL, HLP) per DIN 51524; Phosphate Ester on request |
Engineering Features & Advantages
- Precision Performance: The integrated high-Performance Wet-Pin Solenoid, 24 V DC (HG24) ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original REXROTH OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 120 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
With a maximum operating pressure of 350 bar and a nominal flow capacity of up to 120 L/min, this valve is engineered for precise directional control in demanding industrial applications requiring reliable, repeatable performance.
PRODUCT IMAGES
REXROTH 4WE 10 E50/HG24N9K4/M / R901390857 Solenoid Operated Directional Spool Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WE 10 E50/HG24N9K4/M / R901390857 Solenoid Directional Spool Valve. This Germany-made 24V DC hydraulic component features a reliable spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
