Product Overview
The Rexroth 4WE 10 G5X/EG24N9K4/M (Material No. R901278768) is a direct-operated, solenoid-actuated directional spool valve from the proven 4WE 10 series, size NG10 (CETOP 5 / ISO 4401-05). It controls the start, stop, and direction of hydraulic fluid flow by shifting a precision-ground spool within a hardened valve housing via wet-pin AC or DC solenoids. Configured in a 4-way, 3-position (4/3) function with a “G” type center condition (closed center, all ports blocked in the de-energized state), this valve is engineered for high-pressure industrial circuits requiring reliable load holding and precise directional control. The EG24N9K4 solenoid designation indicates a 24 V DC high-performance wet-pin solenoid with a nominal 30 W rating, an ISO 4400 / DIN EN 175301-803 (DIN 43650) plug-in connector, and a manual override for emergency actuation. As a core component in Rexroth’s modular valve program, it serves as a pilot or main stage in manifold-mounted systems, offering fast response, low leakage, and long service life in continuous-duty applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Spool Valve (4/3 Way, Direct Operated) |
| Model Designation | 4WE 10 G5X/EG24N9K4/M |
| Material Number | R901278768 |
| Size / Interface | NG10 (CETOP 5, ISO 4401-05, NFPA D05) |
| Spool Type / Center Condition | Type “G” — Closed Center (P, A, B, T blocked in neutral) |
| Operating Pressure | Up to 350 bar (ports P, A, B); 210 bar max at port T |
| Nominal Flow Rate | Up to 120 L/min (dependent on spool and pressure drop) |
| Solenoid Voltage | 24 V DC (EG24 designation) |
| Solenoid Power Rating | 30 W nominal (high-performance wet-pin design) |
| Electrical Connection | DIN EN 175301-803 (ISO 4400) plug-in connector, K4 style |
Engineering Features & Advantages
- Precision Performance: The solenoid operated directional spool valve (4/3 way, direct operated) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original REXROTH standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 120 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
As a core component in Rexroth’s modular valve program, it serves as a pilot or main stage in manifold-mounted systems, offering fast response, low leakage, and long service life in continuous-duty applications.
PRODUCT IMAGES
REXROTH 4WE 10 G5X/EG24N9K4/M / R901278768 Solenoid Operated Directional Spool Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WE 10 G5X/EG24N9K4/M / R901278768 Solenoid Directional Spool Valve. This Germany-made 24V DC hydraulic component features a reliable spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
