The REXROTH 4WE 6 J86X/EG24N9K4 is a heavy-duty industrial directional control valve engineered for precise flow direction and reliable performance in demanding hydraulic circuits. This solenoid-actuated, spring-centered unit features a J86X spool type and a 24 V DC wet-pin solenoid with N9 manual override, providing dependable switching and safe manual operation during maintenance or emergency conditions.
REXROTH 4WE 6 J86X/EG24N9K4 Technical Specifications
| Parameter | Value |
|---|---|
| Valve Type | 4/3-way directional control valve |
| Actuation | Solenoid actuated, spring centered |
| Spool Type | J86X |
| Coil Voltage | 24 V DC (EG24) |
| Manual Override | N9 (push-button, concealed) |
| Mounting Pattern | ISO 4401-03 / CETOP 3 / NFPA D03 |
| Max Operating Pressure | 350 bar (5075 psi) |
| Max Flow Rate | 60 L/min (15.8 gpm) |
| Hydraulic Fluid | Mineral oil, HLP/HM per ISO 6743-4 |
| Fluid Temperature Range | -20 °C to +80 °C |
| Viscosity Range | 2.8 to 500 mm²/s |
| Filtration | ISO 4406 (20/18/15) or better |
| Weight | Approx. 1.5 kg |
Key Engineering Features
- Wet-pin solenoid design with high switching force and long service life
- Spring-centered spool returns to neutral position on power loss
- N9 manual override for safe, controlled operation without electrical power
- High-strength cast iron body and hardened spool for durability
- Standard ISO 4401-03 mounting for direct manifold or subplate installation
- Low pressure drop and minimal internal leakage for efficient system performance
Industrial Applications
- Machine tool hydraulic systems
- Presses and forming equipment
- Injection molding machines
- Material handling and lifting equipment
- Mobile and industrial hydraulic power units
- Test stands and specialized automation
For technical inquiries, dimensional drawings, or replacement support for REXROTH 4WE 6 J86X/EG24N9K4, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
REXROTH 4WE 6 J86X/EG24N9K4 Directional Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the REXROTH 4WE 6 J86X/EG24N9K4 Directional Control Valve. This precision-engineered industrial component delivers reliable fluid control for heavy-duty systems.
