Product Overview
The Rexroth 4WE 6 L62/EG24N9K4/T06 (Material Number: R900973205) is a direct-operated, solenoid-actuated directional spool valve from the proven Rexroth 4WE 6 series. Designed for controlling the start, stop, and direction of fluid flow in industrial hydraulic systems, this valve features a 3-position, 4-way (4/3) spool configuration with a “L” type center condition (all ports blocked in the neutral position). The valve is actuated by a high-performance wet-pin AC/DC solenoid (EG24N9K4 designation) rated for 24 V DC, ensuring reliable, fast, and chatter-free switching. With a nominal size of NG6 (CETOP 3 / ISO 4401-03), it is engineered for compact manifold mounting and delivers precise directional control in demanding high-cycle industrial applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Spool Valve (4/3 Way) |
| Model Designation | 4WE 6 L62/EG24N9K4/T06 / R900973205 |
| Nominal Size | NG6 (CETOP 3 / ISO 4401-03-02-0-05) |
| Spool Type / Center Condition | Type “L” — All ports (P, A, B, T) blocked in neutral position |
| Actuation | Two wet-pin solenoids, spring-centered return |
| Solenoid Voltage | 24 V DC (EG24 designation) |
| Electrical Connection | N9 — Individual connection with component plug, DIN EN 175301-803 |
| Operating Pressure | Up to 350 bar (P, A, B ports); 210 bar (T port) |
| Nominal Flow Rate | Up to 60 L/min (NG6 standard) |
| Mounting & Connection | Subplate / Manifold mounting per ISO 4401-03; 4 x M5 mounting bolts |
| Seal Material | NBR (Nitrile) — suitable for mineral oil based hydraulic fluids |
Engineering Features & Advantages
- Precision Performance: The integrated two wet-pin solenoids, spring-centered return ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 60 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
With a nominal size of NG6 (CETOP 3 / ISO 4401-03), it is engineered for compact manifold mounting and delivers precise directional control in demanding high-cycle industrial applications.
PRODUCT IMAGES
Rexroth 4WE 6 L62/EG24N9K4/T06 / R900973205 Solenoid Operated Directional Spool Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WE 6 L62/EG24N9K4/T06 / R900973205 Solenoid Directional Valve. This Germany-made 24 VDC hydraulic component features a 4/3-way design with spring return, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
