Product Overview
The Rexroth 4WE10J5X/HG24N9K4/M (Material Number: R901401552) is a high-performance direct-operated solenoid directional control valve from the renowned 4WE10 series. Engineered by Bosch Rexroth, this 4-way, 3-position (4/3) valve is designed to control the start, stop, and direction of fluid flow in industrial hydraulic systems. Featuring a robust solenoid actuation mechanism and a spring-centered spool, it provides precise directional control for actuators, cylinders, and motors. The “J” spool type offers a specific flow path configuration (P to A, B to T in the neutral position), making it ideal for applications requiring a defined mid-position behavior. With a size 10 (NG10) interface, this valve ensures high flow capacity and reliable switching performance in demanding B2B environments.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Directional Control Valve (4/3 Way) |
| Model Designation | 4WE10J5X/HG24N9K4/M / R901401552 |
| Operating Pressure | Up to 350 bar (Max. working pressure at ports P, A, B) |
| Nominal Flow Rate | Up to 120 L/min (dependent on spool type and pressure differential) |
| Spool Type | Type J (P to A, B to T in neutral; specific crossover characteristics) |
| Actuation | High-Performance Wet-Pin AC/DC Solenoid (24V DC nominal) |
| Mounting & Connection | Subplate Mounting (ISO 4401-05 / CETOP 5 / NG10) |
| Electrical Connection | Connector per DIN EN 175301-803 (Plug-in, with indicator light option) |
| Seal Material | NBR (Nitrile Rubber) – Standard for mineral oil based fluids |
Engineering Features & Advantages
- Precision Spool & Sleeve Design: The hardened and ground spool ensures minimal leakage and precise metering characteristics, providing accurate control over actuator movement and positioning.
- High-Performance Solenoid System: Equipped with a robust, wet-pin solenoid that offers high switching forces, fast response times, and long service life even under high cycling rates.
- Spring-Centered Reliability: The return spring mechanism ensures the spool automatically returns to the defined neutral (center) position upon de-energization, providing fail-safe operation for critical industrial processes.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
The “J” spool type offers a specific flow path configuration (P to A, B to T in the neutral position), making it ideal for applications requiring a defined mid-position behavior.
PRODUCT IMAGES
Rexroth 4WE10J5X/HG24N9K4/M / R901401552 Solenoid Directional Control Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WE10J5X/HG24N9K4/M / R901401552 Solenoid Directional Spool Valve. This Germany-made 24V DC hydraulic component features a reliable spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
