Product Overview
The Rexroth 4WE10U5X/HG24N9K4/M is a direct-operated, solenoid-actuated directional spool valve from the renowned 4WE10 series, engineered by Bosch Rexroth for precise control of start, stop, and direction of hydraulic fluid flow in industrial systems. Featuring a robust 5-chamber housing design and a high-performance wet-pin AC/DC solenoid, this valve delivers reliable switching performance with minimal pressure drop. The “U” spool configuration provides a specific flow path for specialized circuit logic, while the HG24N9K4 solenoid designation indicates a 24V DC high-power solenoid with a nominal 30W rating and integrated manual override. The M suffix denotes a spring-centered, spring-return configuration, ensuring the spool returns to its neutral position upon de-energization. This valve is a critical control component in demanding hydraulic circuits requiring fast response, leak-free operation, and long service life.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Spool Valve |
| Model Designation | 4WE10U5X/HG24N9K4/M |
| Series | 4WE10 (Size 10, NG10 / CETOP 5) |
| Spool Type | Type U (Specific flow configuration) |
| Actuation | Solenoid Operated, Spring Centered / Spring Return |
| Solenoid Voltage | 24V DC (HG24N9K4) |
| Operating Pressure | Up to 315 bar (Max. working pressure at ports P, A, B) |
| Nominal Flow Rate | Up to 120 L/min (dependent on spool type and pressure drop) |
| Mounting & Connection | Subplate Mounting, ISO 4401-05 / CETOP 5 / NFPA D05 Interface |
| Manual Override | Integrated (N9 designation) |
| Seal Material | NBR (Nitrile) / FKM (Viton) available on request |
Engineering Features & Advantages
- Precision Performance: The integrated solenoid Operated, Spring Centered / Spring Return ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Precision-manufactured to original Rexroth specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
The Rexroth 4WE10U5X/HG24N9K4/M is a direct-operated, solenoid-actuated directional spool valve from the renowned 4WE10 series, engineered by Bosch Rexroth for precise control of start, stop, and direction of hydraulic fluid flow in industrial systems.
PRODUCT IMAGES
Rexroth 4WE10U5X/HG24N9K4/M Solenoid Operated Directional Spool Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Rexroth 4WE10U5X/HG24N9K4/M Solenoid Directional Valve. This Germany-made 24V DC hydraulic component features a 4-way, 3-position design with spring return, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
