Product Overview
The Rexroth 4WEH16J7X/6EG24N9EK4 (Material No. R900927456) is a high-performance electro-hydraulic directional spool valve from the proven 4WEH series, size NG16 (Cetop 7 / ISO 4401-07). It is a two-stage valve design in which a pilot-operated solenoid valve controls the main spool of a hydraulically actuated directional valve, enabling the switching of large flow volumes with minimal electrical control power. Configured with a “J” type spool, the valve provides a tandem-center circuit function for precise directional control of actuators in demanding industrial hydraulic systems. The integrated design features a spring-centered main spool, wet-pin AC/DC solenoids with a nominal voltage of 24 V DC, an emergency manual override, and a built-in pilot oil supply and return arrangement, making it a direct-fit, high-reliability solution for manifold-mounted industrial power units.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Electro-Hydraulic Directional Spool Valve (Pilot-Operated, Two-Stage) |
| Model Designation | 4WEH16J7X/6EG24N9EK4 |
| Material Number | R900927456 |
| Nominal Size | NG16 (Cetop 7 / ISO 4401-07-08-0-05) |
| Spool Type | Type “J” — Tandem Center, Spring-Centered |
| Actuation | Two Wet-Pin Solenoids, Spring Return to Center |
| Solenoid Voltage | 24 V DC (EG24 designation) |
| Operating Pressure | Up to 350 bar (main ports); pilot pressure per manufacturer specification |
| Nominal Flow Rate | Up to 300 L/min (NG16 class) |
| Mounting & Connection | Subplate / Manifold Mounting, ISO 4401-07 Interface |
| Electrical Connection | DIN EN 175301-803 (ISO 4400) Connector, with Indicator |
Engineering Features & Advantages
- Precision Performance: The integrated two Wet-Pin Solenoids, Spring Return to Center ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 300 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
The integrated design features a spring-centered main spool, wet-pin AC/DC solenoids with a nominal voltage of 24 V DC, an emergency manual override, and a built-in pilot oil supply and return arrangement, making it a direct-fit, high-reliability solution for manifold-mounted industrial power units.
PRODUCT IMAGES
Rexroth 4WEH16J7X/6EG24N9EK4 / R900927456 Electro-Hydraulic Directional Spool Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WEH16J7X/6EG24N9EK4 / R900927456 Solenoid Operated Directional Spool Valve. This Germany-made 24V DC hydraulic component features a 4-way pilot-operated design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
