Product Overview
The Rexroth 4WRAE6W07-23/G24N9K31/A1V (Material Number: R900932003) is a high-performance, direct-operated proportional directional valve designed for precise control of flow direction and magnitude in industrial hydraulic systems. Manufactured by Bosch Rexroth, this valve features a 4-way, 3-position spool configuration with integrated position feedback and a proportional solenoid actuator. The “W07” spool type provides a specific flow characteristic optimized for fine metering and smooth acceleration/deceleration of actuators. The “23” designates a nominal flow rate of 23 L/min at a pressure drop of 10 bar per metering edge. The “G24” indicates a 24 V DC proportional solenoid, while “N9” specifies the electrical connector type. The “K31” refers to the integrated control electronics (OBE) with a command signal of 0 to ±10 V or 4 to 20 mA. The “A1V” suffix denotes a specific spool variant and seal material (NBR). This valve is a critical component in closed-loop control systems, enabling precise velocity, position, and force control in injection molding machines, presses, and other demanding industrial applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve |
| Model Designation | 4WRAE6W07-23/G24N9K31/A1V / R900932003 |
| Operating Pressure | Up to 315 bar (dynamic), 350 bar (static) |
| Nominal Flow Rate | 23 L/min at Δp = 10 bar per metering edge |
| Mounting & Connection | ISO 4401-03 (CETOP 3) interface; Subplate mounting |
| Actuation | Proportional solenoid, 24 V DC, with integrated control electronics (OBE) |
| Electrical Connector | Connector type N9 (per Rexroth standard, typically 6-pin + PE) |
| Command Signal | 0 to ±10 V or 4 to 20 mA (selectable via OBE) |
| Spool Type | W07 (progressive flow characteristic, closed-center in neutral) |
| Seal Material | NBR (Nitrile Rubber) – A1V variant |
Engineering Features & Advantages
- Precision Performance: The integrated proportional solenoid, 24 V DC, with integrated control electronics (OBE) ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 315 bar and flow rates up to 23 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
This valve is a critical component in closed-loop control systems, enabling precise velocity, position, and force control in injection molding machines, presses, and other demanding industrial applications.
PRODUCT IMAGES
Rexroth 4WRAE6W07-23/G24N9K31/A1V / R900932003 Proportional Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Rexroth 4WRAE6W07-23/G24N9K31/A1V / R900932003 Proportional Directional Valve. This Germany-made 24 VDC hydraulic component features a direct-operated proportional design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
