Product Overview
The Rexroth 4WRKE 10 E100L-35/6EG24K31/A5D3M (material number R900708263) is a pilot-operated, two-stage proportional directional valve with electrical position feedback on the main stage. It is designed for continuous, high-dynamic control of flow direction and flow magnitude in industrial hydraulic systems. The valve consists of a pilot control valve with proportional solenoids and a main stage with position feedback, enabling precise, load-independent control of actuator speed and direction. This valve is a direct-fit replacement for OEM Rexroth proportional valve installations and is widely used in applications requiring high response sensitivity and accurate velocity control.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve (Pilot-Operated, Two-Stage) |
| Model Designation | 4WRKE 10 E100L-35/6EG24K31/A5D3M |
| Material Number | R900708263 |
| Nominal Size | NG10 (Size 10) |
| Nominal Flow Rate | 100 L/min (at Δp = 35 bar per land) |
| Operating Pressure | Up to 350 bar (main stage); pilot stage rated to 315 bar |
| Spool Type | E-type spool with progressive flow characteristics |
| Actuation | Proportional solenoid, 24 V DC (EG24) |
| Electrical Connection | K31 — DIN EN 175301-803 (ISO 4400) connector, component plug |
| Feedback | A5D3M — integrated position feedback on main spool with analog output |
| Mounting Pattern | ISO 4401-05 / CETOP 5 subplate mounting |
| Seal Material | NBR (standard); FKM available on request |
Engineering Features & Advantages
- Precision Performance: The integrated a5D3M — integrated position feedback on main spool with analog output ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 100 L/min, supporting stable operation across the full working range.
- Proportional Control with Feedback: Two-stage design with integrated electronics and position feedback (ET) for precise, repeatable flow control where smooth acceleration and high dynamics are required.
- Matched Replacement: Supplied to the exact Rexroth code 4WRKE 10 E100L-35/6EG24K31/A5D3M, keeping existing mounting and electrical interfaces unchanged.
Typical Industrial Applications
This valve is a direct-fit replacement for OEM Rexroth proportional valve installations and is widely used in applications requiring high response sensitivity and accurate velocity control.
Understanding the Model Code: 4WRKE 10 E100L-35/6EG24K31/A5D3M
Each block of the Rexroth model code describes one attribute of the valve. Use this breakdown together with the specification table above to confirm the exact configuration you need:
| Code Block | Meaning |
|---|---|
| 4WRKE 10 | Proportional Directional Valve (Pilot-Operated, Two-Stage) — NG10 (Size 10) |
| Series 35 | Component series designation — mounting dimensions are unchanged within the series |
| EG24 | Solenoid — 24 V DC |
| K31 | Component plug connection (central connector) |
Always verify the complete code and material number against the nameplate on your existing valve before ordering — body size, spool type and coil voltage must all match.
Choosing the Right Variant
Unlike on/off directional valves, the 4WRKE controls flow proportionally to an electrical command, so a matching proportional control amplifier is required — check your machine’s electronics or ask us to verify. The spool and integrated feedback electronics define the dynamic behaviour of this valve. Related listings:
- REXROTH 4WRKE 10 E50L-33/6EG24ETK31/A1D3M / R90071954 Proportional Directional Valve
- REXROTH 4WRKE 10 E100L-35/6EG24ETK31/A1D3M / R900704216 Proportional Directional Valve
Frequently Asked Questions
What is the difference between this and a standard 4WE directional valve?
A 4WE valve only switches flow on or off; the 4WRKE controls flow proportionally in response to an electrical command — giving smooth acceleration and precise speed control where the machine has a suitable proportional amplifier.
Does this valve include position feedback?
The ET design includes integrated electronics with position feedback (LVDT) on the main spool, improving repeatability and dynamic response — see the specification table for the exact configuration of this unit.
What should I check before ordering?
Confirm the complete code and material number (see nameplate) on your nameplate, and verify that your control electronics match the electrical interface of this valve.
Is the coil voltage important?
Yes — this unit uses a 24 V DC proportional solenoid, and the electronics must match your control circuit.
PRODUCT IMAGES


REXROTH 4WRKE 10 E100L-35/6EG24K31/A5D3M / R900708263 Proportional Directional Valve
