Product Overview
The Rexroth 4WRKE16E1-125L-3X/6EG24ETK31/F1D3M (Material No. R901051897) is a high-response, pilot-operated proportional directional valve from the renowned Rexroth 4WRKE series. Engineered for precise control of flow direction and magnitude in demanding industrial hydraulic systems, this valve utilizes a two-stage design: a pilot stage with a proportional solenoid and a main stage with a position-controlled spool. The “E1” designation indicates a positive spool overlap, ensuring a closed-center condition for load holding and safe system behavior. The “125L” code specifies a nominal flow rate of 125 L/min at a 10 bar pressure drop per land. This valve is a critical component for achieving smooth, accurate, and dynamic motion control in high-performance machinery.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve |
| Model Designation | 4WRKE16E1-125L-3X/6EG24ETK31/F1D3M |
| Material Number | R901051897 |
| Valve Size (NG) | NG16 (Nominal size 16) |
| Actuation Type | Proportional Solenoid with Integrated Position Control |
| Nominal Flow Rate | 125 L/min (at Δp = 10 bar per land) |
| Operating Pressure | Up to 350 bar (P, A, B ports); 315 bar (T port) |
| Spool Type | E1 – Positive Overlap (Closed Center) |
| Electrical Supply | 24 V DC (EG24) |
| Electrical Connector | Component plug, 6-pole + PE (K31) |
| Mounting & Connection | Subplate mounting, ISO 4401-07-07-0-05 (NG16) |
| Seal Material | FKM (Fluoroelastomer) for high-temperature and phosphate ester fluid compatibility |
Engineering Features & Advantages
- Precision Performance: The proportional directional valve delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 125 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
Engineered for precise control of flow direction and magnitude in demanding industrial hydraulic systems, this valve utilizes a two-stage design: a pilot stage with a proportional solenoid and a main stage with a position-controlled spool.
PRODUCT IMAGES
Rexroth 4WRKE16E1-125L-3X/6EG24ETK31/F1D3M / R901051897 Proportional Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WRKE16E1-125L-3X/6EG24ETK31/F1D3M / R901051897 Proportional Directional Valve. This Germany-made 24 VDC hydraulic component features a pilot-operated design with integrated electronics, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
