Product Overview
The Rexroth 4WRKE16W8-200L-3X/6EG24EK31/A1D3M (Material Number R900247386) is a high-response, pilot-operated proportional directional valve with integrated position feedback, designed for precise control of flow direction and magnitude in demanding industrial hydraulic systems. As part of the Rexroth 4WRKE series, this valve features a size 16 (NG16) main stage with a nominal flow capacity of 200 L/min at a 10 bar pressure differential across the valve, and belongs to component series 3X. The valve operates on a two-stage working principle: a proportional pilot valve with a wet-pin DC solenoid controls the pilot pressure, which in turn actuates the main spool of the second stage. An integrated electrical position feedback system continuously monitors main spool position, enabling closed-loop control of spool stroke and therefore precise, load-independent metering of flow. The “W8” spool type provides a specific progressive flow characteristic optimized for smooth acceleration and deceleration of actuators. With a 24 VDC solenoid (EG24) and a spring-centered, fail-safe neutral position, this valve is engineered for applications requiring high dynamic response, excellent repeatability, and reliable directional control of hydraulic actuators in continuous industrial duty.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve (Pilot-Operated, with Position Feedback) |
| Model Designation | 4WRKE16W8-200L-3X/6EG24EK31/A1D3M |
| Material Number | R900247386 |
| Valve Size | NG16 (Size 16) |
| Nominal Flow Rate | 200 L/min (at Δp = 10 bar per land) |
| Spool Type | W8 — Progressive flow characteristic, closed-center |
| Operating Pressure | Up to 350 bar (main stage, standard industrial grade) |
| Pilot Pressure | Typically 25–50 bar (external or internal pilot supply) |
| Solenoid Voltage | 24 VDC (EG24 wet-pin proportional solenoid) |
| Electrical Connection | Component plug, 6-pole (EK31) with position feedback signal |
| Control Type | Proportional solenoid with integrated |
Engineering Features & Advantages
- Precision Performance: The proportional directional valve (pilot-operated, with position feedback) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 200 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
With a 24 VDC solenoid (EG24) and a spring-centered, fail-safe neutral position, this valve is engineered for applications requiring high dynamic response, excellent repeatability, and reliable directional control of hydraulic actuators in continuous industrial duty.
PRODUCT IMAGES
Rexroth 4WRKE16W8-200L-3X/6EG24EK31/A1D3M / R900247386 Proportional Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WRKE16W8-200L-3X/6EG24EK31/A1D3M / R900247386 Proportional Directional Control Valve. This Germany-made 24 VDC hydraulic component features a 4-way, 3-position design with integrated electronics, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
