Product Overview
The Rexroth 4WRLE 16 X200M-30/G24K0/A1M-811 (material number 0811404256) is a pilot-operated, two-stage proportional directional valve from the Rexroth 4WRLE series, designed for high-response, closed-loop control of flow direction and magnitude in industrial hydraulic systems. The valve combines a pilot stage equipped with a proportional solenoid and a main stage with position feedback, enabling precise, continuously variable spool positioning proportional to the electrical command signal. With a nominal size of NG16 and a rated flow of 200 L/min at a 30 bar pressure differential, this valve is engineered for demanding motion-control applications requiring fast response, high resolution, and excellent repeatability. As a proportional directional valve, it regulates both the direction and rate of actuator movement, making it a core component in electrohydraulic control architectures.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve (Pilot-Operated, Two-Stage) |
| Model Designation | 4WRLE 16 X200M-30/G24K0/A1M-811 |
| Material Number | 0811404256 |
| Nominal Size | NG16 (Size 16) |
| Rated Flow | 200 L/min at Δp = 30 bar per land |
| Operating Pressure | Up to 350 bar (working ports); pilot stage rated for high-pressure control |
| Actuation | Proportional solenoid, 24 V DC (G24), with integrated position feedback |
| Spool Type | X200M — progressive flow characteristic, closed-center spool |
| Mounting & Connection | Subplate mounting per ISO 4401 / DIN 24340 (NG16 pattern) |
| Electrical Interface | Central connector with integrated amplifier (A1M configuration) |
Engineering Features & Advantages
- Precision Proportional Metering: The X200M spool profile delivers a finely graduated flow characteristic, enabling smooth, stepless control of actuator velocity with high resolution and minimal hysteresis.
- Integrated Position Feedback: The main spool position is continuously monitored and closed-loop controlled, ensuring accurate, repeatable spool positioning independent of flow forces and pressure fluctuations.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
With a nominal size of NG16 and a rated flow of 200 L/min at a 30 bar pressure differential, this valve is engineered for demanding motion-control applications requiring fast response, high resolution, and excellent repeatability.
PRODUCT IMAGES
Rexroth 4WRLE 16 X200M-30/G24K0/A1M-811 / 0811404256 Proportional Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WRLE 16 X200M-30/G24K0/A1M-811 / 0811404256 Proportional Directional Valve. This Germany-made 24V DC hydraulic component features a 4-way proportional design with integrated electronics, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
