Product Overview
The Rexroth 4WRPEH 6 C3 B04L-30/M/24A1 (Material Number R901382345) is a high-response, direct-operated proportional directional valve with integrated digital on-board electronics (OBE) and electrical position feedback. Designed and manufactured by Bosch Rexroth, this valve belongs to the proven 4WRPEH series and serves as a precision control element for regulating both the direction and magnitude of hydraulic flow in proportion to an electrical input signal. The valve features a nominal size 6 (NG6 / CETOP 3) subplate interface and a 4-way, 3-position spool configuration with a closed-center (C3) design. Its integrated OBE electronics with a ±10 V or 4–20 mA command interface deliver exceptional dynamic response, minimal hysteresis, and outstanding repeatability, making it an ideal choice for closed-loop position, velocity, and force control in demanding industrial and mobile hydraulic systems.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve (4-Way, 3-Position, Direct-Operated with OBE) |
| Model Designation | 4WRPEH 6 C3 B04L-30/M/24A1 / R901382345 |
| Nominal Size | NG6 (CETOP 3 / ISO 4401-03) |
| Spool Type / Center Condition | C3 — Closed Center (all ports blocked in neutral) |
| Nominal Flow Rate | 4 L/min per land at Δp = 10 bar (B04 spool) |
| Operating Pressure | Up to 315 bar (ports P, A, B); 315 bar max at T |
| Command Signal | ±10 V DC (factory default) / 4–20 mA via OBE electronics |
| Supply Voltage | 24 V DC (nominal, per model code “24A1”) |
| Electrical Feedback | Integrated position transducer with closed-loop spool control |
| Mounting & Connection | Subplate mounting per ISO 4401-03-04-0-05; DIN EN 175301-803 (Valve plug) |
Engineering Features & Advantages
- Precision Performance: The proportional directional valve (4-way, 3-position, direct-operated with obe) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 315 bar and flow rates up to 4 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
Its integrated OBE electronics with a ±10 V or 4–20 mA command interface deliver exceptional dynamic response, minimal hysteresis, and outstanding repeatability, making it an ideal choice for closed-loop position, velocity, and force control in demanding industrial and mobile hydraulic systems.
PRODUCT IMAGES
Rexroth 4WRPEH 6 C3 B04L-30/M/24A1 / R901382345 Proportional Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WRPEH 6 C3 B04L-30/M/24A1 / R901382345 Proportional Directional Control Valve. This Germany-made 24 VDC hydraulic component features a 4-way, 3-position design with integrated electronics, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
