Product Overview
The Rexroth 4WRPEH10C3B100L-30/M/24A1 (Material Number R901493886) is a high-response, direct-operated proportional directional valve from the Rexroth 4WRPEH series, engineered for precise, continuous control of flow direction and magnitude in demanding industrial hydraulic systems. Featuring a four-way, three-position spool design with integrated position feedback, this valve converts an analog electrical command signal into a proportional hydraulic output, enabling smooth, infinitely variable actuation of cylinders and motors. The size 10 (NG10 / CETOP 5) valve is actuated by a single proportional solenoid with a spring-centered return, providing fail-safe centering in the event of power loss. Its high-response spool positioning and closed-loop feedback architecture make it a preferred choice for closed-loop motion control, velocity regulation, and force control in plastic injection molding, metallurgical, and machine tool applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve (4-way, 3-position, direct-operated with position feedback) |
| Model Designation | 4WRPEH10C3B100L-30/M/24A1 |
| Material Number | R901493886 |
| Nominal Size | NG10 (CETOP 5 / ISO 4401-05) |
| Spool Type / Function | C3 — E-type spool, closed-center, 4-way, 3-position |
| Nominal Flow | 100 L/min (nominal, at Δp = 10 bar per land) |
| Operating Pressure | Up to 315 bar (P, A, B ports); T port rated to 160 bar |
| Actuation | Single proportional solenoid, spring-centered return |
| Electrical Supply | 24 V DC (24A1 solenoid, integrated control electronics) |
| Command Signal | Analog ±10 V (or 4–20 mA via external amplifier) |
| Mounting & Connection | Subplate mounting per ISO 4401-05-05-0-05 / CETOP 5; DIN EN 175301-803 (ISO 4400) electrical connector |
Engineering Features & Advantages
- Precision Performance: The integrated single proportional solenoid, spring-centered return ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 315 bar and flow rates up to 100 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
Its high-response spool positioning and closed-loop feedback architecture make it a preferred choice for closed-loop motion control, velocity regulation, and force control in plastic injection molding, metallurgical, and machine tool applications.
PRODUCT IMAGES
Rexroth 4WRPEH10C3B100L-30/M/24A1 / R901493886 Proportional Directional Valve
