Product Overview
The Rexroth 4WRPEH6C3B40L-31/M/24F1 (Material Number R901382350) is a high-response, direct-operated proportional directional valve from the Bosch Rexroth 4WRPEH series. Engineered with an integrated digital amplifier (OBE) and closed-loop position control of the main spool, this valve delivers precise, repeatable directional and flow control proportional to an electrical command signal. The “C3” spool design provides a critical-center overlap configuration suited for position and velocity control of actuators, while the “40L” flow rating corresponds to a nominal flow capacity of approximately 40 L/min at a 10 bar (Δp) pressure differential per land. With a standard 24 VDC solenoid actuation and the “F1” electrical interface, this valve is designed for seamless integration into modern industrial control architectures, offering fast response, minimal hysteresis, and excellent flow linearity for demanding motion control tasks.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve (4-Way, 3-Position) |
| Model Designation | 4WRPEH6C3B40L-31/M/24F1 / R901382350 |
| Manufacturer | Bosch Rexroth |
| Actuation Type | Proportional Solenoid with Integrated Digital Amplifier (OBE) |
| Spool Type / Center Condition | C3 — Critical Center Overlap (Closed Center) |
| Nominal Flow Rating | 40 L/min (per land at Δp = 10 bar) |
| Operating Pressure | Up to 315 bar (P, A, B ports); 250 bar (T port) |
| Supply Voltage | 24 VDC (Nominal) |
| Electrical Interface | F1 — Standard Industrial Connector (Component Plug) |
| Mounting Pattern | ISO 4401-03 / CETOP 3 / NG6 Subplate Interface |
| Hysteresis | ≤ 0.2% (with integrated closed-loop spool position control) |
Engineering Features & Advantages
- Precision Performance: The proportional directional valve (4-way, 3-position) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Precision-manufactured to original Rexroth specifications for direct replacement, minimising downtime and eliminating fitment issues.
- Rated Capability: Rated for pressure ratings up to 315 bar and flow rates up to 40 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
The “C3” spool design provides a critical-center overlap configuration suited for position and velocity control of actuators, while the “40L” flow rating corresponds to a nominal flow capacity of approximately 40 L/min at a 10 bar (Δp) pressure differential per land.
PRODUCT IMAGES
Rexroth 4WRPEH6C3B40L-31/M/24F1 / R901382350 Proportional Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Rexroth 4WRPEH6C3B40L-31/M/24F1 / R901382350 Proportional Directional Valve. This Germany-made 24V DC hydraulic component features a 4-way, 3-position design with integrated electronics, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
