Product Overview
The Rexroth 4WRZE 25 W9-220-73/6EG24N9EK31/A1D3M (Material Number R900750197) is a high-response, pilot-operated proportional directional valve from the Rexroth 4WRZE series. It is designed to control the direction and magnitude of flow in industrial hydraulic systems through continuously variable electrical input signals. The valve features a 4-way, 3-position spool configuration with integrated position feedback, enabling precise proportional control of actuator speed and direction. With a nominal flow capacity of 220 L/min at the specified pressure differential, this valve is engineered for demanding applications requiring smooth, accurate motion control and high dynamic response.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Valve (Pilot-Operated, 4-Way, 3-Position) |
| Model Designation | 4WRZE 25 W9-220-73/6EG24N9EK31/A1D3M |
| Material Number | R900750197 |
| Nominal Flow Rate | 220 L/min (at Δp = 10 bar per land) |
| Operating Pressure | Up to 315 bar (working ports); Pilot pressure up to 315 bar |
| Nominal Solenoid Voltage | 24 V DC (EG24) |
| Spool Type | W9 — Progressive flow characteristic, closed center |
| Electrical Connection | Component plug per DIN EN 175301-803 (N9), with integrated electronics (EK31) |
| Mounting & Connection | Subplate mounting per ISO 4401 / DIN 24340 (NG25); 4-way port pattern |
| Seal Material | NBR (N9) — suitable for mineral oil-based hydraulic fluids |
| Control Interface | Analog ±10 V or 4–20 mA command signal; integrated position feedback |
Engineering Features & Advantages
- Precision Proportional Control: The W9 spool with progressive flow characteristic enables fine metering of flow across the entire stroke, ensuring smooth acceleration and deceleration of actuators without hydraulic shock.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
With a nominal flow capacity of 220 L/min at the specified pressure differential, this valve is engineered for demanding applications requiring smooth, accurate motion control and high dynamic response.
PRODUCT IMAGES
Rexroth 4WRZE 25 W9-220-73/6EG24N9EK31/A1D3M / R900750197 Proportional Directional Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH 4WRZE 25 W9-220-73/6EG24N9EK31/A1D3M / R900750197 High-Response Solenoid Directional Poppet Valve. This Germany-made 220V hydraulic component features a high-response pilot control, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
