The REXROTH 5-4WE 10 D50/EG24K40MBG24/M / R901336797 is a heavy-duty industrial directional control valve engineered for precise flow direction and reliable performance in demanding hydraulic circuits. This 4-way, 3-position solenoid-operated valve features a D50 spool type, spring return, and wet-pin AC/DC solenoid with 24 V DC coil, providing dependable switching and long service life.
REXROTH 5-4WE 10 D50/EG24K40MBG24/M / R901336797 Technical Specifications
| Valve Type | 4/3-way directional control valve, solenoid actuated |
| Spool Type | D50 (closed center, P, A, B, T blocked in neutral) |
| Actuation | Wet-pin solenoid, 24 V DC |
| Coil Type | EG24K40MBG24 (24 V DC, 40 W) |
| Mounting Pattern | ISO 4401-05, CETOP 5, NG10 |
| Max. Operating Pressure | 350 bar (5075 psi) |
| Max. Flow Rate | 120 L/min (31.7 gpm) |
| Hydraulic Fluid | Mineral oil based, HLP/HM per ISO 6743-4 |
| Fluid Temperature Range | -20 °C to +80 °C |
| Viscosity Range | 10 to 500 mm²/s |
| Filtration | ISO 4406 (c) 20/18/15 or better |
| Electrical Connection | DIN EN 175301-803, 3-pole + PE |
| Protection Class | IP65 (with mating connector) |
| Seal Material | NBR (Buna-N) |
| Housing Material | Cast iron |
| Weight | Approx. 6.5 kg |
Key Engineering Features
- Wet-pin solenoid design with removable coil for easy maintenance and reduced wear.
- High flow capacity up to 120 L/min with low pressure drop.
- Spring return and spring-centered spool for fail-safe neutral position.
- Rugged cast iron housing for high pressure and harsh industrial environments.
- Standard ISO 4401-05 mounting interface for direct integration.
- Manual override option available for emergency operation.
Industrial Applications
- Hydraulic power units and central systems
- Presses, injection molding machines, and machine tools
- Mobile and industrial hydraulic circuits requiring directional control
- Material handling and lifting equipment
- Steel mills, marine, and offshore hydraulic systems
For technical inquiries, dimensional drawings, or replacement support for REXROTH 5-4WE 10 D50/EG24K40MBG24/M / R901336797, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
REXROTH 5-4WE 10 D50/EG24K40MBG24/M Directional Control Valve
