Product Overview
The Rexroth A6VM107EP2D/63W-VZB020HPB (Material Number: R902223864) is a high-performance axial piston variable displacement motor from the renowned Bosch Rexroth A6VM series. Engineered with a bent-axis rotary group design, this motor converts hydraulic pressure into reliable rotational mechanical power with exceptional efficiency across a wide speed range. The A6VM107 features a nominal displacement of 107 cm³/rev and is equipped with the EP2D control variant, providing electro-proportional displacement control for precise torque and speed regulation in closed-loop hydraulic systems. With its robust swashplate-style bent-axis kinematics, the motor delivers high starting torque, superior low-speed stability, and excellent power density, making it a preferred choice for demanding industrial and mobile hydraulic drive applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Axial Piston Variable Displacement Motor |
| Model Designation | A6VM107EP2D/63W-VZB020HPB |
| Material Number | R902223864 |
| Nominal Displacement | 107 cm³/rev |
| Operating Pressure | Up to 400 bar (nominal), 450 bar (peak) |
| Control Type | EP2D Electro-Proportional Displacement Control |
| Mounting & Connection | Standard ISO / SAE Flange Interface |
| Direction of Rotation | Reversible (Bi-directional operation) |
Engineering Features & Advantages
- Precision Performance: The bent-axis axial piston design with EP2D electro-proportional control enables infinitely variable displacement adjustment, delivering precise torque and speed control with fast dynamic response for closed-loop hydraulic drive systems.
- High Power Density: Compact swashplate-style rotary group achieves high torque output within a minimal installation envelope, ideal for space-constrained mobile and industrial machinery.
- Industrial Reliability: Built for continuous operation under severe industrial conditions with hardened piston/cylinder interfaces, robust bearings, and proven Rexroth manufacturing quality ensuring long service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM Rexroth A6VM107 specifications, ensuring drop-in replacement without modification.
Typical Industrial Applications
This Rexroth A6VM107 axial piston variable displacement motor is widely deployed in demanding hydraulic drive systems, including plastic injection molding machines requiring precise screw drive control, metallurgical presses and rolling mills, construction and marine winch/rotary drive systems, and CNC machine tool rotary indexing tables. Its electro-proportional control makes it particularly suited for applications demanding accurate speed and torque regulation under varying load conditions.
PRODUCT IMAGES
Rexroth A6VM107EP2D/63W-VZB020HPB / R902223864 Axial Piston Variable Displacement Motor
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH A6VM107EP2D/63W-VZB020HPB / R902223864 Axial Piston Variable Displacement Pump. This German-made hydraulic pump features a swashplate design, delivering high power density and reliable fluid flow for heavy-duty industrial systems.
