Product Overview
The Rexroth DBEM10-71/200YG24K4M (Material Number: R901335400) is a high-performance proportional pressure relief valve designed for precise electro-hydraulic pressure control in demanding industrial systems. As part of the Rexroth DBEM series, this valve functions as a pilot-operated pressure relief valve with proportional solenoid actuation, enabling stepless adjustment of system pressure in direct proportion to the electrical command signal. Unlike fixed-setting relief valves, the DBEM10-71/200YG24K4M allows continuous, dynamic pressure regulation via an analog or PWM input, making it ideal for applications requiring variable pressure profiles, soft-start/stop sequences, or closed-loop pressure control. The valve is engineered for subplate mounting in accordance with ISO 6264 (size 10), ensuring drop-in compatibility with standard manifold and subplate interfaces. With a nominal pressure rating of 200 bar and a maximum flow capacity of 71 L/min, this proportional valve delivers reliable, repeatable performance in hydraulic power units, presses, injection molding machines, and other precision-driven industrial equipment.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Pressure Relief Valve (Pilot-Operated, Solenoid Actuated) |
| Model Designation | DBEM10-71/200YG24K4M / R901335400 |
| Nominal Pressure Rating | 200 bar (adjustable via proportional solenoid) |
| Maximum Flow Rate | 71 L/min |
| Actuation Type | Proportional Solenoid (24 V DC, K4M coil designation) |
| Mounting & Connection | Subplate mounting per ISO 6264, size 10 (NG10) |
| Control Signal | Analog / PWM proportional input (0–10 V or 4–20 mA typical) |
| Pressure Adjustment Range | Stepless, proportional to command signal (0–200 bar) |
| Hydraulic Fluid Compatibility | Mineral oil-based hydraulic fluids (HL, HLP, HLPD per DIN 51524) |
| Seal Material | NBR (standard); FKM available for high-temperature or specialty fluids |
Engineering Features & Advantages
- Precision Proportional Control: The proportional solenoid and integrated pressure-compensated pilot stage deliver smooth, stepless pressure adjustment with minimal hysteresis and excellent repeatability, enabling accurate closed-loop pressure regulation in dynamic hydraulic systems.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
With a nominal pressure rating of 200 bar and a maximum flow capacity of 71 L/min, this proportional valve delivers reliable, repeatable performance in hydraulic power units, presses, injection molding machines, and other precision-driven industrial equipment.
PRODUCT IMAGES
Rexroth DBEM10-71/200YG24K4M / R901335400 Proportional Pressure Relief Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Rexroth DBEM10-71/200YG24K4M / R901335400 Proportional Pressure Relief Valve. This Germany-made 24V DC hydraulic component features a piloted design with proportional solenoid, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
