Product Overview
The Rexroth MK 20 G14/V (Material Number R900423328) is a modular throttle check valve from the proven Rexroth MK series, engineered for precise flow control and load-holding functions within industrial hydraulic systems. As a sandwich-style modular valve, it mounts directly between a directional control valve and its subplate in accordance with ISO 4401 / DIN 24340 interface standards, eliminating the need for additional piping. The valve combines a manually adjustable throttle function for regulating actuator speed in one direction with a leak-free seated check function that permits unrestricted reverse flow. This dual-function design makes the MK 20 G14/V an essential component for meter-in and meter-out speed control, load holding, and synchronized motion applications in demanding hydraulic circuits.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Throttle Check Valve (Modular / Sandwich Plate Design) |
| Model Designation | MK 20 G14/V / R900423328 |
| Nominal Size | NG20 (Size 20 modular interface) |
| Adjustment Type | Manual adjustment (G14 spindle / set screw configuration) |
| Operating Pressure | Standard Industrial Grade (Up to 315 bar rated) |
| Flow Direction | Throttled in one direction, free flow via check function in reverse |
| Mounting & Connection | ISO 4401 / DIN 24340 modular sandwich interface, NG20 |
| Sealing | NBR standard (FKM / Viton available on request) |
Engineering Features & Advantages
- Precision Flow Metering: The adjustable throttle spindle enables fine, repeatable regulation of actuator speed, ensuring accurate meter-in or meter-out control across the full working range.
- Integrated Check Function: A robust seated check element allows unrestricted reverse flow, providing reliable load-holding capability and preventing unintended actuator drift.
- Modular Sandwich Construction: Compact NG20 sandwich design integrates directly into existing valve stacks, reducing installation space, piping, and potential leak points.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with hardened internal components for long service life and stable performance.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth OEM standards, ensuring drop-in interchangeability with the R900423328 material number.
Typical Industrial Applications
The Rexroth MK 20 G14/V throttle check valve is widely deployed in heavy industrial hydraulic systems requiring precise speed control and load holding. Typical applications include plastic injection molding machines, metallurgical presses and rolling mills, CNC machine tools and machining centers, as well as construction, marine, and material handling hydraulics where reliable modular flow control is essential for safe and accurate actuator motion.
PRODUCT IMAGES
REXROTH MK 20 G14/V / R900423328 Throttle Check Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH MK 20 G14/V / R900423328 Check Valve. This Germany-made hydraulic component features a poppet-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
