Product Overview
The Rexroth R900727801 (4WE6D6X/EG24N9K4) is a direct-operated, solenoid-actuated directional spool valve from the proven 4WE6 series, engineered by Bosch Rexroth for precise control of start, stop, and direction of hydraulic fluid flow in industrial power units. Featuring a “D” type spool configuration within a 6X (series 60) housing, this valve provides a closed-center, four-way, three-position function that directs pressurized flow to the selected actuator port while returning the opposite port to tank. The EG24N9K4 designation indicates a 24 V DC wet-pin solenoid with a nominal 30 W coil, an ISO 4401-03 (CETOP 3 / NFPA D03) mounting pattern, and a manual override (N9) for emergency actuation. With a maximum operating pressure of 350 bar on P, A, and B ports and 210 bar on T, the R900727801 delivers fast, repeatable spool shifting and low-pressure drop, making it a benchmark component for demanding industrial hydraulic circuits.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Directional Control Valve (Solenoid-Operated Spool Valve) |
| Model Designation | R900727801 / 4WE6D6X/EG24N9K4 |
| Series | Rexroth 4WE6 Series (Size 6, Series 6X) |
| Spool Type | Type “D” — Four-way, three-position, closed center |
| Actuation | Two wet-pin DC solenoids with spring return to center |
| Solenoid Voltage | 24 V DC (EG24), nominal 30 W per coil |
| Manual Override | N9 — Concealed manual emergency actuation |
| Operating Pressure | Up to 350 bar (P, A, B); 210 bar (T port) |
| Nominal Flow Rate | Up to 80 L/min (Size 6 nominal) |
| Mounting & Connection | ISO 4401-03-02-0-05 (CETOP 3 / NFPA D03) subplate interface |
Engineering Features & Advantages
- Precision Performance: The integrated two wet-pin DC solenoids with spring return to center ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Rexroth standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 80 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
With a maximum operating pressure of 350 bar on P, A, and B ports and 210 bar on T, the R900727801 delivers fast, repeatable spool shifting and low-pressure drop, making it a benchmark component for demanding industrial hydraulic circuits.
PRODUCT IMAGES
Rexroth R900727801 / 4WE6D6X/EG24N9K4 Directional Spool Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Rexroth R900727801 4WE6D6X/EG24N9K4 Directional Spool Valve. This Germany-made 24V DC hydraulic component features a solenoid-operated, spring-centered design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
