Product Overview
The Rexroth R901170939 is a high-performance solenoid-actuated directional spool valve engineered for precise control of hydraulic fluid flow direction, start, stop, and pressure regulation within complex industrial hydraulic circuits. Manufactured by Bosch Rexroth, a global benchmark in drive and control technology, this valve belongs to the renowned 4WE series of directional spool valves. It utilizes a robust wet-pin AC or DC solenoid to shift a hardened, precision-ground steel spool within a high-tensile cast iron housing. This design ensures rapid, reliable response times and leak-free operation, making it an essential component for controlling actuators, cylinders, and motors in demanding B2B applications requiring high cycle rates and dependable directional control.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Directional Spool Valve |
| Model Designation | R901170939 |
| Operating Pressure | Up to 350 bar (5075 psi) at Ports P, A, B |
| Mounting & Connection | Subplate Mounting per ISO 4401 / DIN 24340 (NG6 / CETOP 3) |
| Actuation Type | High-Performance Wet-Pin Solenoid |
| Spool Configuration | Spring Return / Spring Centered (Configurable) |
| Flow Rate | Up to 80 L/min (21 GPM) nominal |
Engineering Features & Advantages
- Precision Spool & Sleeve Assembly: The hardened, ground spool and honed sleeve ensure minimal internal leakage, precise metering characteristics, and exceptional resistance to contamination-induced wear, guaranteeing consistent directional control.
- High-Performance Solenoid System: The wet-pin solenoid design provides high switching forces, fast response times, and excellent thermal stability, allowing for high duty cycles and reliable operation in continuous industrial use.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, the valve housing is constructed from high-strength cast iron, offering superior durability and resistance to external impacts and environmental factors.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, ensuring seamless integration into existing Rexroth or compatible hydraulic manifolds without modification.
Typical Industrial Applications
This solenoid directional valve is ideally suited for a wide range of heavy industrial scenarios, including plastic injection molding machines where precise sequencing is critical, metallurgical presses requiring high-pressure control, construction and marine hydraulic systems for reliable actuation, and CNC machine tools where rapid, accurate tool positioning is essential. It is also commonly found in automated assembly lines and material handling equipment.
PRODUCT IMAGES
Rexroth R901170939 Solenoid Directional Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH R901170939 Solenoid Directional Spool Valve. This Germany-made 24V DC hydraulic component features a reliable spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
