Product Overview
The Rexroth RTM 25 S2A-11/440F2H420F15V11-620 (Material Number: R901097464) is a high-performance hydraulic control block engineered by Bosch Rexroth for demanding industrial motion control systems. This assembly functions as a directional spool valve bank, integrating multiple directional control valve sections into a single compact manifold body. Each section utilizes a precision-ground spool and honed bore arrangement to direct pressurized hydraulic fluid to specific actuator ports, enabling controlled extension, retraction, and holding of cylinders or motors. The control block is designed for parallel circuit operation, allowing simultaneous actuation of multiple functions while maintaining stable pressure and flow characteristics across the system. With its robust cast-iron housing and standardized connection interfaces, this Rexroth control block serves as a central hydraulic distribution and directional control hub in mobile and industrial machinery requiring reliable, repeatable valve actuation.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Directional Control Valve / Hydraulic Control Block |
| Model Designation | RTM 25 S2A-11/440F2H420F15V11-620 |
| Material Number | R901097464 |
| Valve Type | Directional Spool Valve (Multi-Section Control Block) |
| Actuation Method | Solenoid / Hydraulic Pilot Actuated |
| Operating Pressure | Standard Industrial Grade (Up to rated bar per Rexroth specification) |
| Mounting & Connection | Standard ISO / Manufacturer Interface |
| Spool Configuration | Precision-ground spool with multiple position options |
| Circuit Type | Parallel circuit with integrated pressure and return galleries |
Engineering Features & Advantages
- Precision Spool Metering: The hardened, precision-ground spool and honed valve bore deliver accurate flow metering and minimal internal leakage, ensuring precise actuator control and repeatable cycle performance in demanding motion sequences.
- Integrated Multi-Section Design: The control block consolidates multiple directional valve functions into a single manifold, reducing piping complexity, minimizing leak points, and simplifying installation in space-constrained machinery.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust cast-iron construction and corrosion-resistant internal components rated for high-cycle hydraulic duty.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM Rexroth standards, ensuring drop-in replacement without modification to existing hydraulic circuits or mounting interfaces.
- Direct Fit Replacement: Precision-manufactured to original Rexroth specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
With its robust cast-iron housing and standardized connection interfaces, this Rexroth control block serves as a central hydraulic distribution and directional control hub in mobile and industrial machinery requiring reliable, repeatable valve actuation.
PRODUCT IMAGES
Rexroth RTM 25 S2A-11/440F2H420F15V11-620 / R901097464 Hydraulic Control Block
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH RTM 25 S2A-11/440F2H420F15V11-620 / R901097464 Proportional Directional Valve. This Germany-made 24V DC hydraulic component features a 4-way proportional design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
