Product Overview
The Rexroth STW0195-23/1VS-24PF6 (Material Number: R901105881) is a high-performance directional spool valve engineered by Bosch Rexroth for precise control of hydraulic fluid flow direction, distribution, and pressure in demanding industrial circuits. As part of the STW series, this valve utilizes a robust spool-in-housing design that directs pressurized fluid to designated actuator ports based on the position of the control spool. The “24PF6” designation indicates a 24 V DC solenoid-actuated configuration with a specific spool type and spring return arrangement, enabling reliable electrical control of hydraulic cylinders, motors, and rotary actuators. This valve is designed for subplate mounting in accordance with ISO 4401 / DIN 24340 standards, ensuring drop-in compatibility with standard industrial manifolds and power units. Its construction delivers fast response, minimal internal leakage, and long service life, making it a critical control component in high-cycle industrial hydraulic systems.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Directional Spool Valve (Solenoid Actuated) |
| Model Designation | STW0195-23/1VS-24PF6 / R901105881 |
| Manufacturer | Bosch Rexroth |
| Actuation Type | 24 V DC Solenoid with Spring Return |
| Operating Pressure | Standard Industrial Grade (Up to 315 bar rated) |
| Mounting & Connection | Subplate Mounting per ISO 4401 / DIN 24340 |
| Spool Configuration | 23/1VS Spool Type (Closed Center / Specific Flow Pattern) |
| Seal Material | NBR (Nitrile) Standard Industrial Seals |
Engineering Features & Advantages
- Precision Spool Metering: The hardened, precision-ground control spool ensures accurate flow direction and minimal internal leakage, providing reliable actuator positioning and repeatable cycle performance.
- Fast Solenoid Response: The 24 V DC wet-pin solenoid delivers rapid switching times, enabling high-cycle operation and precise timing in automated hydraulic sequences.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a robust housing and wear-resistant spool bore that withstands pressure spikes and contamination.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, including ISO 4401 mounting patterns and standard electrical connectors, ensuring drop-in installation without modification.
- Spring Return Fail-Safe: Integrated return spring automatically repositions the spool to its de-energized state upon power loss, enhancing system safety and preventing unintended actuator movement.
Typical Industrial Applications
This Rexroth directional spool valve is widely deployed in heavy industrial scenarios including plastic injection molding machines for mold open/close and injection control
PRODUCT IMAGES
REXROTH STW0195-23/1VS-24PF6 / R901105881 Directional Control Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH STW0195-23/1VS-24PF6 / R901105881 Solenoid Directional Spool Valve. This Germany-made 24V DC hydraulic component features a robust spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
