Product Overview
The Rexroth STW0322-10/3WRCE50V720L-SG24K31C1M (Material Number: R901147272) is a high-performance proportional directional control valve engineered for precise, infinitely variable control of flow direction and magnitude in demanding industrial hydraulic systems. Featuring a 4-way, 3-position spool design with integrated position feedback, this valve operates on the principle of proportional solenoid actuation, where electrical input signals are translated into proportional spool displacement, enabling accurate metering of hydraulic fluid. The “WRCE” designation indicates a pilot-operated, high-response proportional valve with electrical position feedback and integrated control electronics, ensuring exceptional dynamic response and repeatability. As a core component within Rexroth’s renowned proportional and servo valve portfolio, the STW0322-10 series is designed for closed-loop control applications where precise velocity, position, and force regulation are critical to overall system performance and energy efficiency.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional Control Valve (4-Way, 3-Position) |
| Model Designation | STW0322-10/3WRCE50V720L-SG24K31C1M / R901147272 |
| Operating Pressure | Up to 350 bar (nominal working pressure, depending on port configuration) |
| Nominal Flow Rate | 720 L/min (at Δp = 10 bar per land, reference value) |
| Actuation Type | Proportional Solenoid with Integrated Position Feedback (SG24K31C1M) |
| Electrical Supply | 24 V DC Nominal Solenoid Voltage |
| Mounting & Connection | Standard ISO 4401 / DIN 24340 Subplate Mounting Interface |
| Control Electronics | Integrated (OBE) with Analog/Digital Command Interface |
Engineering Features & Advantages
- Precision Proportional Metering: The valve spool is infinitely positioned via proportional solenoids, allowing exact, repeatable control of flow rate and direction proportional to the electrical command signal, essential for accurate velocity and position control in closed-loop systems.
- Integrated Position Feedback: The SG24K31C1M configuration includes an electrical position feedback sensor that continuously monitors spool position, ensuring high hysteresis accuracy, excellent repeatability, and minimal response delay even under varying pressure and flow conditions.
- High Dynamic Response: Designed for fast step responses and high-frequency command tracking, making it ideal for applications requiring rapid acceleration and deceleration of hydraulic actuators without sacrificing stability.
- Robust Industrial Construction: Manufactured to Rexroth’s stringent quality standards with hardened, precision-ground spool and sleeve assemblies, providing long service life and reliable operation in harsh industrial environments.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Precision-manufactured to original REXROTH specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
As a core component within Rexroth’s renowned proportional and servo valve portfolio, the STW0322-10 series is designed for closed-loop control applications where precise velocity, position, and force regulation are critical to overall system performance and energy efficiency.
PRODUCT IMAGES
REXROTH STW0322-10/3WRCE50V720L-SG24K31C1M / R901147272 Proportional Directional Control Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH STW0322-10/3WRCE50V720L-SG24K31C1M / R901147272 High-Response 3-Way Proportional Directional Control Valve. This Germany-made 24V DC hydraulic component features a high-response pilot stage, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
