Product Overview
The Rexroth Z4WE 6 X250-31/EG24N9K4/V/60 (Material No. R901087021) is a direct-operated, solenoid-actuated directional spool valve from the proven Rexroth WE series, size 6 (NG6 / CETOP 3). It controls the start, stop, and direction of hydraulic flow by shifting a precision-ground spool within the valve body via wet-pin AC/DC solenoids. Configured as a 4-way, 3-position (4/3) function with a tandem (X-type) center condition, this valve provides closed-center port blocking with pump unloading to tank in the neutral position, making it ideal for energy-efficient load holding and multi-actuator circuits. The EG24N9K4 designation denotes 24 V DC high-performance solenoids with integrated manual override and a standard DIN EN 175301-803 (ISO 4400) connector, while the /60 indicates the current component series. Engineered for high flow capacity relative to its compact size, this valve is a direct-fit replacement for OEM Rexroth installations in demanding industrial hydraulic systems.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Directional Spool Valve (4/3-way, direct-operated) |
| Model Designation | Z4WE 6 X250-31/EG24N9K4/V/60 |
| Material Number | R901087021 |
| Nominal Size | NG6 (CETOP 3 / ISO 4401-03) |
| Spool Type / Center Condition | Type X (tandem center — P to T open, A/B blocked in neutral) |
| Operating Pressure | Up to 350 bar (ports P, A, B); 210 bar max at port T |
| Nominal Flow Rate | Up to 60 L/min (size 6 optimized spool geometry) |
| Solenoid Voltage | 24 V DC (EG24 high-performance wet-pin solenoid) |
| Electrical Connection | DIN EN 175301-803 (ISO 4400) 3-pole connector |
| Manual Override | Integrated N9 detent-style manual actuation (both ends) |
Engineering Features & Advantages
- Precision Performance: The solenoid directional spool valve (4/3-way, direct-operated) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original REXROTH OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 60 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
Engineered for high flow capacity relative to its compact size, this valve is a direct-fit replacement for OEM Rexroth installations in demanding industrial hydraulic systems.
PRODUCT IMAGES
REXROTH Z4WE 6 X250-31/EG24N9K4/V/60 / R901087021 Solenoid Directional Spool Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH Z4WE 6 X250-31/EG24N9K4/V/60 / R901087021 Solenoid Directional Spool Valve. This Germany-made 24V DC hydraulic component features a robust spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
