Product Overview
The Rexroth ZDR6DA2-46/150YM is a direct-operated, three-way pressure reducing valve designed for precise secondary circuit pressure regulation in industrial hydraulic systems. Manufactured by Bosch Rexroth, this valve belongs to the proven ZDR6 series, which is engineered to maintain a constant reduced outlet pressure regardless of fluctuations in the primary system pressure or changes in flow demand. The “DA” designation indicates a direct-operated pressure reducing function with a pressure gauge connection port, while the “2” specifies the pressure adjustment spring range. The “46” denotes the nominal size (NG6 / CETOP 3 mounting pattern), and “150YM” identifies the pressure rating and adjustment type. This valve is a critical component in circuits requiring a stable, lower-pressure branch derived from a higher-pressure main supply, such as clamping, pilot, or control circuits.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pressure Control Valve (Pressure Reducing Valve) |
| Model Designation | ZDR6DA2-46/150YM |
| Manufacturer | Bosch Rexroth |
| Nominal Size | NG6 (CETOP 3 / ISO 4401-03) |
| Operating Pressure | Up to 150 bar (secondary pressure adjustment range) |
| Maximum Primary Pressure | Up to 315 bar (inlet port P1) |
| Adjustment Type | Manual adjustment with hexagon socket and locknut (YM variant) |
| Mounting & Connection | Subplate mounting, ISO 4401-03-02-0-05 / CETOP 3 interface |
| Port Connections | P1 (inlet), P2 (reduced outlet), T (tank/return), G (gauge port) |
| Seal Material | NBR (Buna-N) standard; FKM available on request |
| Fluid Compatibility | Mineral oil based hydraulic fluids (HL, HLP, HLPD, HVLP) |
| Fluid Temperature Range | -20°C to +80 |
Engineering Features & Advantages
- Precision Performance: The pressure control valve (pressure reducing valve) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Precision-manufactured to original REXROTH specifications for direct replacement, minimising downtime and eliminating fitment issues.
- Rated Capability: Rated for pressure ratings up to 150 bar, supporting stable operation across the full working range.
Typical Industrial Applications
The Rexroth ZDR6DA2-46/150YM is a direct-operated, three-way pressure reducing valve designed for precise secondary circuit pressure regulation in industrial hydraulic systems.
PRODUCT IMAGES
REXROTH ZDR6DA2-46/150YM Pressure Reducing Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine REXROTH ZDR6DA2-46/150YM Pressure Reducing Valve. This German-made hydraulic component features a direct-acting design, delivering precise pressure control and reliable fluid regulation for heavy-duty industrial systems.
