Product Overview
The ROTALINK SP2569-3 is a miniature solenoid valve engineered for precise fluid and gas control within compact industrial and process systems. Operating on a direct-acting solenoid principle, this valve provides rapid, reliable switching of media flow in response to electrical signals, making it ideal for integration into space-constrained manifolds, analytical instrumentation, and pneumatic control circuits. Its miniature form factor does not compromise performance; the SP2569-3 delivers consistent sealing, low power consumption, and long cycle life, ensuring dependable service in demanding process environments where accuracy and repeatability are critical.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Miniature Solenoid Valve (Process & Pneumatic) |
| Model Designation | SP2569-3 |
| Operating Pressure | Standard Industrial Grade (Up to 10 bar typical for miniature solenoid valves) |
| Mounting & Connection | Compact manifold or sub-base mounting; barbed or threaded port options |
| Actuation Type | Direct-acting solenoid |
| Body Material | Corrosion-resistant thermoplastic or anodized aluminum |
| Seal Material | NBR or FKM (media compatible) |
| Electrical Connection | Plug-in or flying lead (standard industrial) |
| Response Time | Fast switching (typically <10 ms) |
Engineering Features & Advantages
- Precision Performance: Direct-acting solenoid design ensures reliable operation from zero pressure differential, with rapid response and consistent sealing for accurate media control.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and high cycle life suitable for demanding process environments.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, allowing drop-in replacement without system modification.
- Compact Footprint: Miniature size enables high-density mounting in manifolds and space-limited control panels.
- Low Power Consumption: Optimized coil design reduces electrical load, ideal for battery-powered or energy-sensitive applications.
Typical Industrial Applications
The ROTALINK SP2569-3 miniature solenoid valve is widely used in analytical and medical instrumentation, pneumatic automation systems, packaging machinery, and process control skids. Its precise metering and fast response make it suitable for dosing, piloting larger valves, and switching air or inert gas lines in CNC machine tools, laboratory equipment, and compact industrial manifolds.
PRODUCT IMAGES
ROTALINK SP2569-3 Miniature Solenoid Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine ROTALINK SP2569-3 Solenoid Directional Control Valve. This Germany-made 24V DC hydraulic component features a 4-way 3-position design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
