Product Overview
The SCHMALZ SCP-25 NO-FS RP-VD (Part No. 10.02.02.03738/01) is a pneumatically operated vacuum generator engineered for reliable vacuum handling within industrial automation and process systems. Operating on the venturi principle, this multi-stage ejector uses compressed air to generate vacuum directly at the point of use, eliminating the need for a separate vacuum pump circuit. The unit is configured in a Normally Open (NO) valve configuration with a non-return function (FS) and is supplied with a vacuum connection interface designated RP-VD. As a compact, decentralized vacuum source, it integrates into pick-and-place, gripping, and material handling systems where fast evacuation and stable holding force are critical.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Vacuum Generator (Ejector) — Process & Pneumatic Valve |
| Model Designation | SCP-25 NO-FS RP-VD |
| Part Number | 10.02.02.03738/01 |
| Valve Function | Normally Open (NO) with non-return / vacuum retention function (FS) |
| Operating Principle | Multi-stage venturi ejector, compressed-air driven |
| Operating Pressure | Standard industrial compressed air supply (typically 4–6 bar) |
| Mounting & Connection | RP-VD vacuum connection interface; standard pneumatic port connections |
Engineering Features & Advantages
- Precision Performance: Multi-stage venturi design delivers high suction capacity and rapid evacuation for fast cycle times in automated handling.
- Integrated Non-Return Function: The FS feature maintains vacuum at the gripping point even after the air supply is interrupted, safeguarding the workpiece against drop during power or air loss.
- Normally Open Configuration: The NO valve logic provides immediate vacuum release behavior suited to specific control sequences and fail-safe requirements.
- Industrial Reliability: Built for continuous operation under severe industrial conditions with minimal maintenance due to the absence of moving wear parts in the ejector stage.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SCHMALZ OEM standards for the SCP-25 series.
Typical Industrial Applications
This vacuum generator is widely deployed in automated pick-and-place systems, packaging and palletizing machinery, plastic injection molding part removal, sheet metal and glass handling, and general pneumatic gripping stations within CNC and assembly lines. Its decentralized design makes it particularly suitable for end-of-arm tooling on industrial robots and for processes requiring fast, reliable vacuum generation at the point of use.
PRODUCT IMAGES
SCHMALZ SCP-25 NO-FS RP-VD / 10.02.02.03738/01 Vacuum Generator
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SCHMALZ SCP-25 NO-FS RP-VD / 10.02.02.03738/01 Solenoid Directional Seat Valve. This German-made hydraulic component features a normally open, spring return design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
