Product Overview
The SCHMALZ SCPMc 10 S04 NC M8-6 PNP is a compact, pneumatically operated vacuum generator designed for decentralized vacuum handling in automated industrial systems. As a member of the SCHMALZ SCPMc series, this unit utilizes the venturi principle to produce vacuum directly at the point of use, eliminating the need for centralized vacuum pumps and long vacuum lines. The integrated normally closed (NC) solenoid valve controls the compressed air supply to the ejector, while the PNP output signal provides a direct interface to modern PLC control systems. With an M8-6 electrical connection and a 4 mm air port configuration, this vacuum generator is engineered for precise, energy-efficient gripping, pick-and-place, and handling tasks in packaging, electronics assembly, and general automation.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Vacuum Generator (Ejector) with Integrated Solenoid Valve |
| Model Designation | SCPMc 10 S04 NC M8-6 PNP |
| Operating Pressure | Standard Industrial Grade (2 – 6 bar optimized) |
| Mounting & Connection | M8-6 Electrical Connector / 4 mm Pneumatic Port |
Engineering Features & Advantages
- Precision Performance: Venturi-based vacuum generation delivers rapid evacuation and stable holding force directly at the suction point, minimizing cycle times and pressure losses.
- Integrated NC Solenoid Control: The normally closed solenoid valve ensures vacuum is only generated when energized, reducing compressed air consumption and improving energy efficiency.
- PNP Signal Output: Provides a clean, PLC-compatible feedback signal for vacuum monitoring and closed-loop process control.
- Industrial Reliability: Built for continuous operation under severe industrial conditions with robust construction and minimal maintenance requirements.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SCHMALZ SCPMc series specifications for drop-in integration.
Typical Industrial Applications
This vacuum generator is widely deployed in automated pick-and-place systems for packaging machinery, electronic component handling and PCB assembly, robotic end-effectors for small part manipulation, and general factory automation lines requiring decentralized vacuum gripping. It is also suitable for sheet metal handling, injection molding machine part removal, and sorting systems in logistics and material handling operations.
PRODUCT IMAGES
SCHMALZ SCPMc 10 S04 NC M8-6 PNP Vacuum Generator
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SCHMALZ SCPMc 10 S04 NC M8-6 PNP Vacuum Generator. This German-made automation component features a compact ejector design, delivering reliable vacuum generation for efficient material handling in industrial systems.
