Product Overview
The Schneider Electric BDM4532S0138 / RECM345/3 D024 5SH0 is a high-performance solenoid-operated directional control valve engineered for precise hydraulic circuit management in demanding industrial environments. This 4-way, 3-position (4/3) valve utilizes a robust spool-and-sleeve design, actuated by dual 24V DC solenoids, to direct hydraulic flow with exceptional repeatability and minimal pressure drop. As a critical component in centralized hydraulic power units and manifold assemblies, it enables reliable start, stop, and reversal of actuators, cylinders, and motors. The RECM345/3 series is recognized for its durable wet-armature solenoid construction and hardened spool surfaces, ensuring long service life even under high cycle rates and contaminated fluid conditions.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Standard Directional Control Valve (Solenoid Operated) |
| Model Designation | BDM4532S0138 / RECM345/3 D024 5SH0 |
| Operating Pressure | Up to 350 bar (5075 psi) rated for continuous industrial duty |
| Mounting & Connection | Standard ISO 4401 / CETOP 5 (NG10) subplate mounting interface |
| Valve Configuration | 4-way, 3-position (4/3), closed-center spool (5SH0 spool type) |
| Actuation | Dual 24V DC wet-armature solenoids with manual override |
| Flow Rate | Up to 120 L/min (31.7 GPM) nominal |
| Fluid Compatibility | Mineral oil based hydraulic fluids (ISO VG 32-68), HLP/HLVP |
Engineering Features & Advantages
- Precision Spool Metering: The 5SH0 spool profile provides fine-tuned flow control and smooth actuator deceleration, minimizing shock and pressure spikes during directional changes.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with hardened spool and sleeve for wear resistance and extended cycle life exceeding 10 million operations.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, including the ISO 4401 mounting pattern and standard 24V DC solenoid connections.
- Low Leakage Design: Precision-ground spool-to-bore clearance ensures minimal internal leakage, improving system efficiency and reducing heat generation.
- Robust Solenoid Construction: Wet-armature solenoids provide high force, low noise, and protection against environmental ingress (IP65 rated coil housing).
Typical Industrial Applications
This solenoid directional control valve is ideally suited for heavy industrial scenarios including plastic injection molding machines (clamp and ejector circuits), metallurgical presses (ram direction
PRODUCT IMAGES
SCHNEIDER ELECTRIC BDM4532S0138 / RECM345/3 D024 5SH0 Solenoid Directional Control Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SCHNEIDER ELECTRIC BDM4532S0138 / RECM345/3 D024 5SH0 Solenoid Directional Control Valve. This France-made 24V DC hydraulic component features a reliable spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
