Product Overview
The SCHNEIDER S340 (Part No. 11.426.0601) is a high-performance hydraulic directional spool valve engineered for precise control of fluid flow direction, distribution, and actuator sequencing in demanding industrial hydraulic circuits. Manufactured by Schneider Hydraulik, a recognized name in precision hydraulic components, this standard directional control valve utilizes a hardened, precision-ground spool mechanism that shifts within a close-tolerance bore to route pressurized oil to designated work ports. As a central control element in industrial power transmission systems, the S340 governs the start, stop, direction, and neutral positioning of hydraulic cylinders and motors, ensuring reliable and repeatable machine motion in continuous-duty applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Standard Directional Control Valve (Spool Type) |
| Model Designation | S340 11.426.0601 |
| Manufacturer | Schneider Hydraulik |
| Operating Pressure | Standard Industrial Grade (Up to rated bar per manufacturer data) |
| Actuation Method | Spool Actuation (Manual / Mechanical / Solenoid per configuration) |
| Mounting & Connection | Standard ISO / Manufacturer Interface |
| Sealing | High-pressure industrial seals for internal and external leakage control |
Engineering Features & Advantages
- Precision Spool Metering: The hardened, precision-lapped spool and matched bore deliver accurate flow metering and minimal internal leakage, ensuring consistent actuator speed and position control across the operating range.
- Low Pressure Drop: Optimized internal flow passages reduce pressure loss across the valve, improving overall system efficiency and reducing heat generation in continuous-duty circuits.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with wear-resistant spool surfaces and robust body construction that withstand high cycle rates and pressure spikes.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, allowing drop-in replacement without modification to manifolds, piping, or control wiring.
Typical Industrial Applications
The SCHNEIDER S340 11.426.0601 directional spool valve is suited for a wide range of heavy industrial hydraulic systems, including plastic injection molding machines requiring precise mold open/close and injection sequencing, metallurgical presses and rolling mill equipment, construction and marine hydraulic power packs, and CNC machine tools where accurate directional control of cylinders and motors is essential. Its robust spool design also makes it appropriate for general industrial automation, material handling equipment, and mobile hydraulic circuits demanding dependable directional flow control.
PRODUCT IMAGES
SCHNEIDER S340 11.426.0601 Hydraulic Directional Spool Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SCHNEIDER S340 11.426.0601 Solenoid Directional Spool Valve. This German-made 24V DC hydraulic component features a robust spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
