Product Overview
The Schubert & Salzer 7020/050V102-C1—–S—-NKO / 4081514 is a pneumatically actuated angle seat valve engineered for precise shut-off and control of neutral and aggressive media in industrial process lines. Manufactured by Schubert & Salzer, a recognized specialist in process valve technology, this valve utilizes a piston-type pneumatic actuator acting on an inclined valve spindle, delivering reliable bidirectional sealing and high flow capacity with minimal pressure loss. The angle seat design optimizes flow geometry, making it ideal for high-cycle, fast-response duties in fluid handling, water treatment, and general process automation systems where dependable isolation and long service life are essential.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pneumatic Angle Seat Valve (Process & Pneumatic Valve) |
| Model Designation | 7020/050V102-C1—–S—-NKO / 4081514 |
| Nominal Size | DN50 (2″) angle seat configuration |
| Actuation Type | Pneumatic piston actuator (single/double acting per model code) |
| Operating Pressure | Standard Industrial Grade (up to rated process pressure per body rating) |
| Control Air Pressure | Typical 4–10 bar instrument air supply |
| Mounting & Connection | Standard ISO / Manufacturer Interface (threaded or flanged per configuration) |
Engineering Features & Advantages
- Precision Performance: Inclined seat geometry provides high flow coefficients (Kv) with low pressure drop and reliable bubble-tight shut-off across the full stroke.
- Fast Pneumatic Actuation: Piston actuator delivers rapid open/close cycling, well suited to automated process sequences and high-frequency duty.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust body and actuator construction resistant to wear and media exposure.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM standards, ensuring drop-in interchangeability for Schubert & Salzer 7020 series installations.
Typical Industrial Applications
Commonly deployed in water and wastewater treatment plants, chemical and petrochemical dosing lines, food and beverage process skids, steam and thermal fluid circuits, and general industrial fluid handling systems requiring automated on/off control of neutral or aggressive media.
PRODUCT IMAGES
Schubert & Salzer 7020/050V102-C1—–S—-NKO / 4081514 Pneumatic Angle Seat Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SCHUBERT & SALZER 7020/050V102-C1—–S—-NKO / 4081514 Solenoid Directional Control Valve. This Germany-made 24V DC hydraulic component features a 4/2-way spool design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
