Product Overview
The Siemens VVF42.65-63C (S55204-V156) is a 2-port flanged control valve engineered for precise modulation of flow in hydronic heating, cooling, and industrial process systems. As part of Siemens’ VVF42 series, this valve features a robust cast iron or ductile iron body with a linear or equal-percentage characterized plug, providing accurate flow control across a wide range of operating conditions. The valve is designed for use with Siemens electromagnetic actuators (such as the SKD, SKB, or SKC series) and is suitable for both open and closed-loop control applications. Its flanged connection ensures secure, leak-free installation in high-flow industrial pipelines, making it a reliable component for demanding process and pneumatic valve applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | 2-Port Flanged Control Valve (Process & Pneumatic Valve) |
| Model Designation | VVF42.65-63C / S55204-V156 |
| Nominal Size (DN) | DN65 (2 ½”) |
| Flow Coefficient (kvs) | 63 m³/h |
| Operating Pressure | Up to 1600 kPa (16 bar) static; differential pressure dependent on actuator |
| Mounting & Connection | Flanged per ISO 7005-2 / EN 1092-2, face-to-face per EN 558-1 |
| Body Material | Cast Iron (EN-GJL-250) or Ductile Iron (EN-GJS-400-18-LT) |
| Plug / Trim | Stainless Steel, characterized plug (linear or equal-percentage) |
| Actuator Compatibility | Siemens SKD, SKB, SKC series electromagnetic actuators |
| Media Temperature Range | -10 °C to +150 °C (depending on actuator and stem sealing) |
Engineering Features & Advantages
- Precision Flow Control: Characterized plug design ensures accurate, repeatable modulation of flow for stable process control and energy-efficient operation.
- Industrial Reliability: Robust flanged body construction and corrosion-resistant trim are built for continuous operation under severe industrial conditions, including high differential pressures and temperature fluctuations.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SIEMENS OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
Its flanged connection ensures secure, leak-free installation in high-flow industrial pipelines, making it a reliable component for demanding process and pneumatic valve applications.
PRODUCT IMAGES
SIEMENS VVF42.65-63C / S55204-V156 2-Port Flanged Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SIEMENS VVF42.65-63C / S55204-V156 2-Way Modulating Control Valve. This Germany-made 24V AC/DC hydraulic component features a magnetic actuator, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
