Product Overview
The Siemens VXF42.150-315C (S55204-V180) is a high-performance 3-port flanged control valve engineered for precise regulation of hot water, chilled water, and steam in building automation and industrial process systems. As part of Siemens’ VXF42 series, this valve features a robust cast iron or ductile iron body with a flanged connection, designed for mixing or diverting service in closed-loop hydronic circuits. The VXF42.150-315C is typically paired with Siemens electro-hydraulic or magnetic actuators (e.g., SKD, SKB, or SQL series) to provide accurate modulating control, ensuring stable temperature and flow regulation in demanding HVAC and process applications. Its 3-port configuration allows for either mixing (two inlets, one outlet) or diverting (one inlet, two outlets) operation, making it a versatile component in district heating, cooling, and industrial fluid control systems.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | 3-Port Flanged Control Valve (Mixing / Diverting) |
| Model Designation | VXF42.150-315C / S55204-V180 |
| Nominal Size (DN) | DN150 (6-inch) |
| Flow Characteristic | Equal percentage or linear (depending on actuator/trim) |
| Operating Pressure | Standard Industrial Grade (up to PN16 / 16 bar) |
| Mounting & Connection | Flanged per ISO 7005-2 / EN 1092-2 |
| Body Material | Cast Iron (EN-GJL-250) or Ductile Iron (EN-GJS-400-18-LT) |
| Stem & Trim Material | Stainless Steel |
| Seat Leakage Class | Class IV (metal-to-metal) or Class VI (soft-seated) per IEC 60534-4 |
| Actuator Compatibility | Siemens SKD, SKB, SQL, or equivalent electro-hydraulic / magnetic actuators |
Engineering Features & Advantages
- Precision Flow Control: The 3-port design enables accurate mixing or diverting of fluid streams, maintaining stable temperature and flow rates in complex hydronic systems.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a robust cast iron body and stainless steel trim for long service life and corrosion resistance.
- Direct Fit Replacement: Precision-manufactured to original SIEMENS specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
Its 3-port configuration allows for either mixing (two inlets, one outlet) or diverting (one inlet, two outlets) operation, making it a versatile component in district heating, cooling, and industrial fluid control systems.
PRODUCT IMAGES
SIEMENS VXF42.150-315C / S55204-V180 3-Port Flanged Control Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SIEMENS VXF42.150-315C / S55204-V180 2-Way Modulating Control Valve. This Germany-made 24V AC/DC hydraulic component features a pressure-compensated plug design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
