Product Overview
The SMC AW40-04DE-B is a modular pneumatic filter regulator from the SMC AW series, engineered to condition compressed air in industrial pneumatic circuits. This unit combines a high-efficiency particulate filter element with a precision pressure-reducing regulator in a single compact body, removing water droplets, oil mist, and solid contaminants while delivering a stable, repeatable downstream set pressure. As a process and pneumatic valve component, it serves as a critical air preparation device protecting directional control valves, cylinders, and actuators from pressure fluctuation and particulate ingress. The AW40-04DE-B is configured with a 1/2 inch port size, a relieving pressure regulation mechanism, and an integrated pressure gauge, making it a direct-fit solution for OEM and MRO pneumatic panel requirements.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Process & Pneumatic Valve — Filter Regulator (Air Preparation Unit) |
| Model Designation | AW40-04DE-B |
| Series / Body Size | SMC AW40 Series (Body Size 40) |
| Port Size | 04 = 1/2 inch (Rc/NPT/G depending on thread option) |
| Operating Pressure | Standard Industrial Grade (Up to rated bar, per SMC AW40 specification) |
| Regulation Type | Relieving pressure regulation with integrated pressure gauge |
| Filtration Function | Particulate and condensate removal with manual drain |
| Mounting & Connection | Standard ISO / SMC Modular Interface (bracket or panel mount compatible) |
Engineering Features & Advantages
- Precision Performance: The AW40-04DE-B delivers accurate, repeatable pressure regulation with minimal droop, ensuring stable actuator force and consistent cycle-to-cycle behavior in pneumatic control loops.
- Integrated Air Treatment: Combining filtration and regulation in one modular body reduces piping joints, leak paths, and panel footprint compared to separate filter and regulator installations.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a robust body and serviceable filter element for long maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC AW40 series OEM standards, allowing drop-in replacement without panel modification.
Typical Industrial Applications
The SMC AW40-04DE-B is widely deployed in plastic injection molding machines, metallurgical presses, CNC machine tools, packaging and assembly automation, and general construction and marine pneumatic systems. It is equally suited to centralized compressed air distribution panels where reliable pressure regulation and clean air delivery are essential for downstream directional valves, proportional valves, and pneumatic actuators.
PRODUCT IMAGES
SMC AW40-04DE-B Pneumatic Filter Regulator
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SMC AW40-04DE-B Filter Regulator. This Japan-made 0.05-0.85 MPa pneumatic component features a modular FRL design, delivering leak-free, reliable air preparation for heavy-duty industrial systems.
