Product Overview
The SMC ITV1050-011CL is a precision electro-pneumatic proportional valve from the SMC ITV series, engineered to deliver continuously variable, stepless pressure control in response to an analog electrical input signal. Unlike conventional on/off solenoid valves, this unit employs a high-resolution proportional control mechanism that regulates output pressure in direct proportion to a 0–10 VDC or 4–20 mA command signal, enabling accurate, repeatable pressure modulation within pneumatic circuits. The ITV1050-011CL is a direct-operated, single-stage proportional pressure regulator featuring an integrated pressure sensor for closed-loop feedback, ensuring stable output regardless of supply pressure fluctuations or downstream flow variations. With its compact body, low hysteresis, and fast response characteristics, this valve serves as a critical control element in industrial automation systems where precise, dynamic air pressure regulation is essential for process consistency and product quality.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Electro-Pneumatic Proportional Valve (Process & Pneumatic Valve) |
| Model Designation | ITV1050-011CL |
| Operating Pressure | Standard Industrial Grade (set pressure range 0.005–0.9 MPa; supply pressure up to 1.0 MPa) |
| Mounting & Connection | Standard ISO / SMC Interface (Rc 1/4 port threads, bracket or panel mount) |
| Control Signal Input | Analog 0–10 VDC or 4–20 mA (selectable by model suffix) |
| Output Pressure Range | 0.005–0.9 MPa (0.05–9 bar) |
| Power Supply | 24 VDC ±10% |
| Hysteresis & Linearity | ≤1% F.S. hysteresis; ≤1% F.S. linearity |
| Response Time | ≤0.1 s (typical, at rated conditions) |
| Fluid Medium | Compressed air (filtered, non-lubricated or lubricated) |
| Ambient / Fluid Temperature | 0–50 °C ambient; 0–60 °C fluid |
Engineering Features & Advantages
- Precision Performance: The electro-pneumatic proportional valve (process & pneumatic valve) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
With its compact body, low hysteresis, and fast response characteristics, this valve serves as a critical control element in industrial automation systems where precise, dynamic air pressure regulation is essential for process consistency and product quality.
PRODUCT IMAGES
SMC ITV1050-011CL Electro-Pneumatic Proportional Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SMC ITV1050-011CL Electro-Pneumatic Proportional Valve. This Japan-made 24V DC valve features a precise pressure control function, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
