Product Overview
The SMC ITV2030-322L3 is a precision electro-pneumatic regulator engineered by SMC Corporation, a global leader in pneumatic and industrial automation technology. This advanced proportional pressure control device converts an analog electrical input signal (0–10 VDC or 4–20 mA, depending on configuration) into a linearly proportional pneumatic output pressure, enabling continuous, stepless pressure regulation within a closed-loop control architecture. Unlike conventional mechanical regulators that require manual adjustment, the ITV2030-322L3 integrates a high-resolution solenoid actuator, internal pressure sensor, and electronic feedback circuit to deliver exceptional pressure stability and repeatability. As a member of the SMC ITV2000 series, this unit is purpose-built for demanding industrial environments where precise, repeatable air pressure control is critical to process quality, force modulation, and system responsiveness. Its compact inline body design and threaded port connections allow direct integration into existing pneumatic circuits without extensive modification, making it an ideal solution for both new installations and OEM replacement applications.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Electro-Pneumatic Regulator (Process & Pneumatic Valve) |
| Model Designation | ITV2030-322L3 |
| Series | SMC ITV2000 Series |
| Operating Pressure Range | 0.005 – 0.9 MPa (0.05 – 9.0 bar) standard set pressure range |
| Input Signal | Analog electrical signal (DC voltage or current, model-dependent) |
| Port Size | 1/4 Rc (PT) threaded ports |
| Mounting & Connection | Inline body mount with threaded pneumatic ports; electrical connector per SMC standard |
| Control Method | Closed-loop electronic feedback with integral pressure sensor |
| Fluid | Compressed air (filtered, non-lubricated or lubricated) |
Engineering Features & Advantages
- Precision Proportional Control: The ITV2030-322L3 delivers highly linear and repeatable output pressure proportional to the electrical input signal, enabling accurate remote setpoint control and seamless integration with PLC or DCS process control systems.
- Closed-Loop Feedback Stability: An internal pressure sensor continuously monitors output pressure and feeds the signal back to the electronic control circuit, compensating for supply pressure fluctuations and downstream flow variations to maintain stable setpoint pressure.
- Industrial Reliability: Constructed with robust internal diaphragm and solenoid components rated for continuous industrial duty cycles, ensuring long service life and minimal maintenance in demanding automation environments.
- Direct Fit Replacement: Precision-manufactured to original SMC specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
Its compact inline body design and threaded port connections allow direct integration into existing pneumatic circuits without extensive modification, making it an ideal solution for both new installations and OEM replacement applications.
PRODUCT IMAGES
SMC ITV2030-322L3 Electro-Pneumatic Regulator
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SMC ITV2030-322L3 Electro-Pneumatic Proportional Valve. This Japan-made 24V DC valve features a precise pressure control function, delivering reliable, leak-free fluid control for heavy-duty industrial systems.
