Product Overview
The SMC SS5J3-60PGD1-X109F is a high-performance solenoid valve manifold from the SMC SS5J series, engineered for precise directional control of compressed air and inert gases in demanding industrial automation environments. This manifold integrates multiple 5-port solenoid valve stations onto a common base, allowing centralized control of several pneumatic actuators from a single compact unit. The SS5J3 series is a 5/3-way valve configuration with a closed-center spool, providing reliable mid-position blocking for actuator holding applications. The “60” designation indicates a 6 mm port size, while the “PGD1” suffix specifies the electrical connection and manual override configuration. The “-X109F” denotes a factory special specification, typically involving custom sealing materials or lubrication-free operation for specific OEM requirements. This manifold is designed for direct mounting to SMC’s SS5J series base manifold system, enabling quick installation, simplified maintenance, and reduced piping complexity in pneumatic control panels.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Valve Manifold (Pneumatic Directional Control) |
| Model Designation | SS5J3-60PGD1-X109F |
| Valve Series | SMC SS5J Series (5-Port Solenoid Valve) |
| Valve Function | 5/3-Way, Closed Center |
| Port Size | 6 mm (60 designation) |
| Operating Pressure | 0.1 to 0.7 MPa (Standard Pneumatic Range) |
| Electrical Connection | PGD1 Configuration (DIN Connector / Grommet Type) |
| Manual Override | Non-Locking Push Type (Standard) |
| Mounting & Connection | Manifold Base Mounting (SMC SS5J Series Compatible) |
| Special Specification | -X109F (Factory Special: Sealing / Lubrication Variant) |
| Body Material | Aluminum Alloy / Resin Composite |
| Seal Material | NBR (Nitrile |
Engineering Features & Advantages
- Precision Performance: The solenoid valve manifold (pneumatic directional control) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
- Rated Capability: Rated for pressure ratings of 0.1 to 0.7 MPa (Standard Pneumatic Range), supporting stable operation across the full working range.
Typical Industrial Applications
The SS5J3 series is a 5/3-way valve configuration with a closed-center spool, providing reliable mid-position blocking for actuator holding applications.
PRODUCT IMAGES
SMC SS5J3-60PGD1-X109F Solenoid Valve Manifold
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SMC SS5J3-60PGD1-X109F Solenoid Valve. This Japan-made 24VDC hydraulic component features a 5-port design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
