Product Overview
The SMC VXZ240FZ2A is a pilot operated 2-port solenoid valve engineered by SMC Corporation, a global leader in pneumatic and process valve technology. This normally closed (N.C.) valve utilizes a two-stage pilot actuation principle: the solenoid pilot stage responds to an electrical signal, creating a pressure differential that drives the main valve poppet to open or close the primary flow path. This design allows the compact solenoid coil to control significantly higher flow rates and line pressures than a direct-acting valve of comparable size. The VXZ240FZ2A is configured for 2-port (inlet/outlet) on/off control of compatible media, making it a reliable choice for automated fluid and gas control in industrial process systems, water treatment, and general pneumatic circuits.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pilot Operated 2-Port Solenoid Valve (Process & Pneumatic Valve) |
| Model Designation | VXZ240FZ2A |
| Valve Function | 2-Port, 2-Position, Normally Closed (N.C.) |
| Actuation Principle | Pilot Operated (Diaphragm / Poppet Main Stage) |
| Operating Pressure | Standard Industrial Grade (Up to rated bar; consult SMC datasheet for media-specific limits) |
| Mounting & Connection | Standard SMC Port Interface (threaded body connection) |
| Coil Voltage | Standard AC/DC options per SMC VXZ series configuration |
| Seal & Body Material | Corrosion-resistant body with elastomer sealing suited to compatible media |
Engineering Features & Advantages
- Precision Performance: The pilot operated poppet/diaphragm design delivers fast, repeatable on/off response and reliable sealing, enabling accurate control of flow with minimal pressure drop across the valve.
- High Flow in Compact Form: Pilot actuation allows the small solenoid to switch higher flow rates and line pressures than direct-acting equivalents, optimizing panel space without sacrificing capacity.
- Industrial Reliability: Built for continuous duty operation under demanding industrial conditions, with a robust coil and durable sealing system for long service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC VXZ series standards, ensuring drop-in replacement without modification.
Typical Industrial Applications
The SMC VXZ240FZ2A is widely deployed in automated process and pneumatic systems, including water and fluid treatment plants, industrial process control and dosing lines, packaging and food-processing machinery, and general factory automation where reliable 2-port on/off solenoid control of compatible media is required.
PRODUCT IMAGES
SMC VXZ240FZ2A Pilot Operated 2-Port Solenoid Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SMC VXZ240FZ2A Solenoid Valve. This Japan-made 24V DC hydraulic component features a 2-port pilot-operated design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
