Product Overview
The SMC VZS2350-4DO is a high-performance solenoid-operated directional control valve from the SMC VZS2000 series, engineered for precise pneumatic and process fluid control in demanding industrial environments. Utilizing a robust poppet or spool-type actuation mechanism, this valve delivers reliable on/off switching of compressed air and compatible process media with fast response times and consistent sealing integrity. As a core component within SMC’s VZS series, the VZS2350-4DO is designed for manifold or sub-base mounting, enabling compact multi-valve assemblies in centralized control panels. Its solenoid pilot actuation ensures low power consumption while maintaining high flow capacity, making it an ideal choice for automated manufacturing lines, packaging machinery, and process control systems requiring dependable directional flow management.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Valve (Pneumatic / Process Directional Control) |
| Model Designation | VZS2350-4DO |
| Series | SMC VZS2000 Series |
| Valve Function | 5-Port, 2-Position / 3-Position Directional Control |
| Actuation Type | Solenoid Pilot Operated |
| Operating Pressure | Standard Industrial Grade (0.1 – 0.7 MPa typical for pneumatic service) |
| Mounting & Connection | Sub-base / Manifold Mounting, ISO Standard Interface |
| Coil Voltage | 24 VDC (standard) / 110 VAC / 220 VAC options available |
| Port Size | 1/8″ – 1/4″ (Rc / NPT / G thread options) |
| Seal Material | NBR / FKM (depending on media compatibility) |
Engineering Features & Advantages
- Precision Performance: Fast solenoid response and tight spool-to-body clearances ensure accurate directional flow switching with minimal internal leakage, critical for high-cycle automated processes.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust coil insulation and wear-resistant sealing elements for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC VZS series manifold configurations, ensuring drop-in replacement without modification.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
Its solenoid pilot actuation ensures low power consumption while maintaining high flow capacity, making it an ideal choice for automated manufacturing lines, packaging machinery, and process control systems requiring dependable directional flow management.
PRODUCT IMAGES
SMC VZS2350-4DO Solenoid Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SMC VZS2350-4DO Solenoid Operated Directional Control Valve. This Japan-made hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
